Prohibited sentences are for review purposes only, not for describing the product. For the wheeled lift dual-arm teleoperation body, first search for the following: do not write 17 degrees of freedom for the whole machine, do not write 650×512×1700 mm, approximately 120 kg, lift 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Do not write 8 kg as the rated payload. Do not write battery life in hours. If a search hit is found, replace it with the original sentence from the product page; do not explain it as “approximately the same.”
Prohibited mixed writing
Other frequent cross-page errors include: merging the three-column kit into a single unit, writing 130 N, 65 mm, 5 kg, and 2 kg as one number, writing charging time as battery life, writing the number of cover camera channels as the standard list, and collapsing RM65-B-V and RM75-B-V into a single model number.
External brand logos do not appear. Success rates from external papers do not appear. The total hours of the data marketplace do not appear, because what the current homepage publicly shows are scenarios, samples, fields, quality notes, and licensing — not an hour count.
There is only one replacement principle: replace with the original sentence from /product-body-lift.html. If the original sentence does not state a capability, write “not given on the page.”

How to Use This Page in This Version
The review checklist applies to the wheeled lift dual-arm teleoperation body, not to “common industry phrasing.” Step one: search for these sentences: do not write 17 degrees of freedom for the whole machine, do not write 650×512×1700 mm, approximately 120 kg, lift 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Do not write 8 kg as the rated payload. Do not write battery life in hours. If a hit is found, replace it with the original sentence from /product-body-lift.html. Step two: search for high-frequency cross-page terms: 6 hours, 17 degrees of freedom, dual-arm rated 8 kg, 3 depth channels, one kit, force feedback across the full lineup, 2-hour battery life, 130 newtons equals 5 kilograms. These terms may only remain if they genuinely appear in the original sentences on this page.
Step three: search for brands and papers. External whole-machine brand logos do not appear. Paper success rates, USD costs, and data counts do not appear. Hour totals not published on the homepage do not appear. Human egocentric video is not labeled as robot motion.
Step four: search for combined terms: "comprehensive parameters", "full-series configuration", "standard configuration includes main arm and gripper", "system accuracy". None of these terms appears as a specification row on any of the five cards. If they appear in the manuscript, break them back into the original sentences from each page, or delete them.
After making the replacements, read through the data dictionary and the contract appendix once more. If the two are still inconsistent, update the dictionary and appendix to match the product page — not the other way around. The appendix may copy: RMC-AIDAL; 640×450×1780 mm; approximately 80 kg; lift 900 mm; vertical 0–2.4 m; arm reach 633 mm; rated 5 kg; self-weight 8 kg; repeatability ±0.05 mm; differential drive 1.5 m/s; slope climbing 5°; positioning ±10 mm / ±3°; Orin 64G + 1T SSD; lithium iron phosphate DC 48V 20Ah, hours not specified.
Line-by-Line Verification
Degrees of freedom. In the robotic arm parameter table, model RM75-B-V has 7 degrees of freedom per arm. The product page does not disclose the total degrees of freedom for the whole machine; do not fill in 17 or 20. This line only states the number and locations of joints that have already been made public. It does not evaluate intelligence, and it does not automatically include the waist, legs, neck, or whole-machine total that are not named on the page. When writing the action vector, create channels only for the body parts named in this line; leave unnamed body parts blank. Do not write blank as 0, because 0 would be treated by training scripts as a real angle. Do not fill in the degrees-of-freedom integer from another device after this line to make the numbers add up. If the master–slave joint order is not given on the page, mark it as pending written configuration confirmation; do not number it yourself. During review, search for incorrect whole-machine degrees of freedom. The action vector creates channels only for the body parts named in this line; unnamed body parts are left blank, not filled with 0.
Load and mass. Single-arm rated load 5 kg. The 8 kg in the parameter table is the single-arm self-weight. The dual-arm rated 8 kg previously written on the cover conflicts with the parameter table; the parameter table takes precedence. The full-machine mass of approximately 80 kg is the overall machine mass. The numbers in this row must be read aloud with their subject: rated load, self-weight, full-machine mass, envelope, friction, or gripping force. If the subjects differ, they cannot be merged into a single number, nor can conversions be performed that are not given on the page. If field objects are heavier, this does not retroactively change the specification; conversely, a larger specification does not prove that every grasping method reaches that limit. The tool mass is undetermined; do not write the arm's rated load as the graspable object mass. The acceptance checklist retains the original units. During review, search for sentences that write self-weight or gripping force as rated load. During acceptance, read the subject first and then the number; if the subjects are inconsistent, split into two rows.
Dimensions and scale. Model RMC-AIDAL. Stowed dimensions 640 × 450 × 1780 mm. Chassis 640 × 450 × 250 mm. This line describes exterior or structural dimensions, used to check doorways, elevators, tabletops, or transport; it is not an operating height, nor is it an arm reach. Do not add it to the vertical range. If a figure shows protrusions, antennas, or a person’s standing position that are not in this line, note separately that they are not part of the specification. If weight appears in an adjacent line, do not write it into the dimension sentence. During review, search for the exterior dimensions of another machine. Doorways, elevators, and transport are checked against the exterior dimensions only; do not treat this line as an operating height.
Operating range. Lift travel 900 mm; vertical working range 0–2.4 m (also written as 0–2400 mm in the table). Single-arm reach 633 mm. Overhang beyond the chassis on one side is 790 mm; the original text does not mark a unit at that point, but it is listed alongside millimeters in the same sentence, so write it externally as 790 mm and retain this note. This line describes the range that the hand or the lift can reach; the definitions must follow the original sentences: vertical working range, arm reach, motion radius, or travel — these cannot be added together or renamed. If “excluding end effector” is written, it must remain in the figure caption. When the original text does not mark a unit, retain the note “unit not marked”; do not delete it for the sake of tidiness. During review, search for sentences that add together different range definitions. The figure caption retains the range definitions from the original sentences, as well as the words “excluding end” or “unit not marked.”
Motion. Two-wheel differential drive, speed 1.5 m/s, slope climbing 5°. Positioning accuracy ±10 mm / ±3°. This line describes how the ground base or main arm moves. Four-wheel steering-drive, differential drive, in-place rotation radius, and rotational speed are terms for different mechanisms and cannot be substituted for one another. Published speed is a capability, not a recommended teaching speed; teaching can be slower, but the slower speed is written into the experimental conditions and is not written back into the specification. Do not borrow slope climbing or positioning data from other pages for pages that do not list them. During review, search for sentences that mix up differential drive, four-wheel steering-drive, and rotational speed. The teaching speed can be lower, but the lower speed is written into the conditions and does not change the published capability in this line.
Power. The battery is lithium iron phosphate DC 48V 20Ah. This document dated 2026-08-03 does not state battery life in hours. Do not fill in approximately 6 hours, and do not rewrite it as 48V 31Ah or approximately 4 hours. This line retains only the electrical terms that appear on the page: voltage, capacity, battery life, charging, current, or power. If there are no “hours,” write battery life not given; do not fill the gap with hours from a neighboring page. Do not rename charging time as battery life. Rated and maximum values must be listed separately. Retain “approximately” for approximate values. Do not sum the ampere-hours of multiple devices and present the total as one device’s battery. During review, search for the 6-hour figure borrowed from elsewhere and for charging time written as battery life. Hours, charging, or current that do not appear remain as not given; do not copy them in from a neighboring page.
Perception and computing. Main controller Nvidia Jetson AGX Orin 64G, plus a 1T solid-state drive. Standard vision configuration is D435 ×1, wide-angle cameras ×2, voice module ×1. If the cover page states 3 depth channels plus 2 wide-angle channels, which conflicts with the list, the specification follows the list. D435 line: ideal ranging 0.3–3 m; depth ≤1280×720, ≤90 fps; RGB 1920×1080, 30 fps; field of view 69°×42°; rolling shutter. Navigation separately lists depth camera ×1, IMU + encoder ×1, LiDAR ×1, safety edge ×1, ultrasonic ×2. This line takes inventory of the items already specified in sensors, computing, or communications, and retains the words standard, included as standard, optional, and selectable. An optional item that is not checked does not count. When the cover page and the list conflict, cite the list, but do not pretend the cover page sentence does not exist. Head-mounted devices and gloves do not enter this line. Processors, drive capacities, or camera channel counts that are not written out must not be drawn into the system diagram. During review, search for cover-page channel counts written as standard delivery. Optional sensors that are not purchased do not enter this data dictionary.
End effector. The recommended configuration lists gripper CTAG2F90-D ×2. The standard configuration quantity list does not include a gripper. RMG22-65 is on a separate product page. This line states where contact or grasping occurs. Quick-change, compatible, and recommended are not models already in the box. The finger-ring fixture on the main arm is not an end-effector gripper. Force, travel, and payload remain preserved as-is in their respective lines; they are not merged into a single system metric because they are mounted on a particular body. For flange and protocol mapping that are not given, write pending confirmation; do not write plug-and-play. During review, search for unordered grippers written as already included. “Supports” or “compatible” without a model number cannot be treated as delivered.
Boundaries. The standard configuration robotic arm is listed as RM65-B-V ×2, while the robotic arm parameter table lists model RM75-B-V. Both model numbers are retained; lock them before placing the order; do not collapse them into one. This line is a boundary deliberately kept separate on the page: another model, another column, another product page, or an interface that still requires project confirmation after modularization. A boundary is not a defect note; it prevents verbally buying two pages as one. When writing a proposal, copy the boundary into “not included in this order.” If a device that is not included is added later, open a new configuration sheet; do not go back and change the body name in old samples. During review, search for the two model numbers collapsed into one. Devices within the boundary must be ordered separately; do not rename old samples to say they already include it.
Configuration column. The recommended configuration is RM75-B-V ×2, two-wheel differential chassis ×1, gripper CTAG2F90-D ×2. Teleoperation options are servo teleoperation, backpack teleoperation, and mobile teleoperation; these are not in the standard configuration quantity list. This line distinguishes standard, recommended, and optional. Recommended and optional items are not delivered unless checked. When the standard line and the parameter table line disagree, keep both lines and use “locked for this order” to indicate which one is actually delivered, rather than striking out one line in the order without signing off. Prices and lead times are not written into this line’s restatement. During review, search for recommended items written as standard. Unchecked recommended and optional items are written as not delivered on the order.
May be excerpted. The following may be copied into the appendix: RMC-AIDAL; 640×450×1780 mm; approximately 80 kg; lift 900 mm; vertical 0–2.4 m; arm reach 633 mm; rated 5 kg; self-weight 8 kg; repeatability ±0.05 mm; differential drive 1.5 m/s; slope climbing 5°; positioning ±10 mm / ±3°; Orin 64G + 1T SSD; lithium iron phosphate DC 48V 20Ah, hours not given. This is the type of line that may be pasted into the appendix: it has a subject, includes units, and can be traced back to the original sentence on the product page. When pasting, retain the words approximately, not included, not given, optional, and recommended. Do not convert and keep only the result. If the same number has different meanings on two pages, write it as two separate lines in the appendix. Do not mix test protocols into specification excerpts. During review, confirm that the appendix has not lost the original line after conversion. When pasting into the appendix, paste the words approximately, not included, and optional together with the values.
Do not write. Do not write 17 degrees of freedom for the whole machine, do not write 650×512×1700 mm, approximately 120 kg, lifting 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Do not write 8 kg as rated load. Do not write battery life in hours. This line is a negative statement for review purposes. It does not describe what the equipment can do; it only prevents writing in hours, degrees of freedom, load subject, or cover slogans from adjacent pages. If the negative statement is hit, revert to the original product page sentence without explaining it as "close enough". Do not write in success rates from external papers or total hours not published on this site. The negative statement itself does not enter promotional slogans. If manuscript retrieval hits the negative statement, revert to the original product page sentence.
| Projects | Public-Facing Positioning of This Page |
|---|---|
| Degrees of Freedom | In the robotic arm parameter table, model RM75-B-V has 7 degrees of freedom per arm. The product page does not publish the total degrees of freedom for the whole unit; do not fill in 17 or 20. |
| Load and Mass | Single-arm rated payload 5 kg. The 8 kg in the parameter table is the single-arm self-weight. The cover previously stated a dual-arm rated payload of 8 kg, which conflicted with the parameter table; the parameter table takes precedence. The total unit weight of approximately 80 kg is the overall mass. |
| Form Factor and Scale | Model RMC-AIDAL. Folded dimensions 640 × 450 × 1780 mm. Chassis 640 × 450 × 250 mm. |
| Operating Range | Lifting stroke 900 mm, vertical working range 0–2.4 m (also written as 0–2400 mm in the table). Single-arm reach 633 mm. Single-side overhang beyond the chassis is 790 mm; the original text did not specify a unit at that point, but since it appears alongside millimeters in the same sentence, it is written externally as 790 mm with this note retained. |
| Motion | Two-wheel differential drive, speed 1.5 m/s, climbing slope 5°. Positioning accuracy ±10 mm / ±3°. |
| Power | The battery is lithium iron phosphate DC 48V 20Ah. This document dated 2026-08-03 does not state battery life in hours. Do not add approximately 6 hours, and do not rewrite it as 48V 31Ah or approximately 4 hours. |
| Perception & Compute | Main controller Nvidia Jetson AGX Orin 64G, with an additional 1T solid-state drive. Standard vision configuration is D435 ×1, wide-angle cameras ×2, voice module ×1. If the cover states 3 depth channels plus 2 wide-angle channels, this conflicts with the list; the specifications follow the list. D435 row: ideal ranging 0.3–3 m; depth ≤1280×720, ≤90 fps; RGB 1920×1080, 30 fps; field of view 69°×42°; rolling shutter. Navigation separately lists depth camera ×1, IMU + encoder ×1, LiDAR ×1, safety edge ×1, ultrasonic ×2. |
| End Effector | The recommended configuration lists gripper CTAG2F90-D ×2. The standard configuration quantity table does not include a gripper. RMG22-65 is a separate product page. |
| Boundary | The standard configuration lists the robotic arm as RM65-B-V ×2, while the robotic arm parameter table lists the model as RM75-B-V. Both model numbers are retained; lock one before placing the order — do not collapse them into a single number. |
| Configuration Panel | Recommended configuration is RM75-B-V ×2, two-wheel differential chassis ×1, gripper CTAG2F90-D ×2. Teleoperation options are servo teleoperation, backpack teleoperation, and mobile teleoperation; these are not included in the standard configuration quantity table. |
| Excerptable | Attachment copy: RMC-AIDAL; 640×450×1780 mm; approximately 80 kg; lifting 900 mm; vertical 0–2.4 m; reach 633 mm; rated 5 kg; self-weight 8 kg; repeatability ±0.05 mm; differential drive 1.5 m/s; slope climbing 5°; positioning ±10 mm / ±3°; Orin 64G + 1T SSD; lithium iron phosphate DC 48V 20Ah, hours not specified. |
| Do not write | Do not write 17 degrees of freedom for the whole unit, and do not write 650×512×1700 mm, approximately 120 kg, lifting 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Do not write 8 kg as the rated payload. Do not write battery life in hours. |

Relationship to Public Methods and Adjacent Pages
Prohibiting mixed writing is both an editorial rule and a delivery rule. The following sentences have already caused or are prone to cause misunderstanding in the product copy on this site, and new articles will no longer use them.
Do not attribute the approximately 6 hours of the folding model to the lift model. Do not describe the lift model as having 17 degrees of freedom for the whole machine, nor as 650×512×1700 mm, approximately 120 kg, lifting 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Those figures belong to a different publicly documented machine, not to this RMC-AIDAL page. Do not write the arm's self-weight of 8 kg as the dual-arm rated payload. Do not merge RM65-B-V from the standard list and RM75-B-V from the arm table into a single model number. Do not write the cover's "3 depth + 2 wide-angle" as delivered; the standard vision configuration is one D435 depth camera plus two wide-angle cameras. Do not write the left/right extension of 790 as a bare number without units, nor pretend the original text printed a unit.
Do not merge the kit's three columns into one machine, and do not write force feedback for the local column. Do not write RMG22-65's 130 N, 65 mm, 5 kg, and 2 kg as the same "5." Do not write the wheeled humanoid's 40 Ah battery and approximately 2-hour charge time as 2-hour endurance. Do not cite brand logos that do not appear on this site. Do not write external paper success rates as TOBI measured results.
This article uses the three sentences most commonly written incorrectly for this product as counterexamples and provides replacement sentences.
Before handing off to a colleague
Review uses search, not full reading. Create a search table of negative sentences and high-frequency cross-page terms, and run it once each against the article, attachments, and data dictionary. On a hit, replace; do not add "basically consistent" next to it. The search table also includes external brand identifiers and paper success rates. After replacement, sample three rows of numbers and go back to the product page to verify the subject. If the subject is wrong, even if the number matches, it counts as a hit. The review record retains the search terms and the original sentences after replacement. The search table goes into the version repository and is committed together with the article. Changing only the article without updating the search record counts as an incomplete review. The search record logs hit counts. A zero hit count must also be recorded, showing the search was run. The three sampled rows must state the subject and the product page location. If the subject check fails, the entire article is rejected, not just those three rows, because errors of this kind usually occur in more than one place.
First, submit the retrieval table together with the article.
Second, record even if the hit count is zero.
Third, spot-check three rows to verify the subject.
Fourth, if the subject fails, the entire document is returned.
Fifth, the same number with a different subject still counts as a match.
Sixth, do not write "basically consistent" next to a hit. After retrieval is complete, the list of hit terms is appended to the internal record at the end of the document, not to the public page. The public page retains only the original sentence after replacement. The internal record is used for the next review, not for external promotion.
