Literature is used to enumerate questions, not to borrow success rates. Questions related to the wheeled lift dual-arm teleoperation platform are: does the action space equal the publicly stated degrees of freedom of the slave or master side, does the observation equal the cameras on the list, does the chassis move, is the end-effector opening/closing included in the vector, and is the timestamp agreed separately.
Document Location
ALOHA discusses dual-arm master-slave control and action chunking, Mobile ALOHA discusses mobile dual-arm, Diffusion Policy discusses imitation-learned visuomotor policies, UMI discusses a handheld gripper rather than a full platform, and Open X-Embodiment discusses pooling across robots, where the embodiment must be labeled. These sentences can be written into the "source of questions" section of a proposal. Do not copy the authors' success rates, sample counts, or costs.
What the wheeled lifting dual-arm teleoperation body can answer is only what the product page has already stated: the single-arm degrees of freedom for the robotic arm specification table model RM75-B-V is 7. The product page does not publish the whole-machine degrees of freedom; do not fill in 17 or 20. The main controller is Nvidia Jetson AGX Orin 64G, with an additional 1T solid-state drive. Standard vision configuration is D435 ×1, wide-angle cameras ×2, voice module ×1. If the cover states 3 depth channels plus 2 wide-angle channels, this conflicts with the list; the specification follows the list. D435 line: ideal ranging 0.3–3 m; depth ≤1280×720, ≤90 fps; RGB 1920×1080, 30 fps; field of view 69°×42°; rolling shutter. Navigation separately lists depth camera ×1, IMU + encoder ×1, LiDAR ×1, safety edge ×1, ultrasonic ×2. The recommended configuration lists grippers CTAG2F90-D ×2. The standard configuration quantity table does not include grippers. RMG22-65 is a separate product page. All other questions remain unanswered until the written configuration is provided.
Do not write "using the system from the above paper." TOBI does not have the equipment list for those experiments, and the wheeled lifting dual-arm teleoperation body is not the robot in those papers.

How to Use This Page in This Version
The literature section of a proposal uses a question checklist, not a scorecard. The checklist has five questions: Is the action space equal to the degrees of freedom or master-slave columns published for the wheeled lifting dual-arm teleoperation body? Is the observation equal to the cameras in the list? Is the chassis included in the actions? Is the end-effector opening/closing listed separately? Is the timestamp handled separately? For any of the five questions that can be answered from the product page, the answer must be the original sentence. The single-arm degrees of freedom for the robotic arm specification table model RM75-B-V is 7. The product page does not publish the whole-machine degrees of freedom; do not fill in 17 or 20. The main controller is Nvidia Jetson AGX Orin 64G, with an additional 1T solid-state drive. Standard vision configuration is D435 ×1, wide-angle cameras ×2, voice module ×1. If the cover states 3 depth channels plus 2 wide-angle channels, this conflicts with the list; the specification follows the list. D435 line: ideal ranging 0.3–3 m; depth ≤1280×720, ≤90 fps; RGB 1920×1080, 30 fps; field of view 69°×42°; rolling shutter. Navigation separately lists depth camera ×1, IMU + encoder ×1, LiDAR ×1, safety edge ×1, ultrasonic ×2. The recommended configuration lists grippers CTAG2F90-D ×2. The standard configuration quantity table does not include grippers. RMG22-65 is a separate product page. Two-wheel differential drive, speed 1.5 m/s, slope climbing 5°. Positioning accuracy ±10 mm / ±3°.
For anything that cannot be answered, write "not published." Do not fill in blanks using the experimental setups of ALOHA, Mobile ALOHA, Diffusion Policy, UMI, or Open X-Embodiment. Those works use their own robots and their own success definitions. TOBI is not the author of those experiments, and the wheeled lifting dual-arm teleoperation body is not the platform in those papers.
The only connections that can be written are methodological: leader-follower teleoperation requires the leader and follower to share the same action space; mobile manipulation requires recording the chassis; the handheld gripper route is deliberately not a whole-machine; cross-robot aggregation requires annotating embodiment differences. These are research questions derived from reading the literature, not performance guarantees.
The final sentence of the literature section is fixed as: "Success rates, data duration, and cost are per the original papers and are not transcribed to this product." Then direct the reader back to /product-body-lift.html, not to an external PDF as if it were a specification sheet.
Line-by-Line Verification
Degrees of freedom. In the robotic arm parameter table, model RM75-B-V has a single-arm degree-of-freedom count of 7. The product page does not publish the whole-machine degree-of-freedom count; do not fill in 17 or 20. This row only states the joint count and body parts that have already been made public. It does not evaluate intelligence, and it does not automatically include waist, legs, neck, or a whole-machine total that the page does not name. When writing the action vector, only create channels for the body parts present in this row; leave absent body parts blank. Do not write blanks as 0, because 0 will be treated by training scripts as a real angle. Do not fill in the integer degrees of freedom from another device after this row to make the numbers add up. If the master-slave joint order is not given on the page, mark it as pending written configuration confirmation; do not number it yourself. For the action space in literature questions, answer with this row, not with the joint count of the robot in the paper. The action vector only creates channels for the body parts named in this row; body parts not named are left blank and not filled with 0.
Payload and mass. The single-arm rated payload is 5 kg. The 8 kg in the specification table is the single-arm self-weight. The dual-arm rated payload of 8 kg previously written on the cover conflicts with the specification table; the specification table takes precedence. The whole-machine mass is approximately 80 kg. The numbers in this line must be read with their subjects: rated, self-weight, whole-machine mass, envelope, friction, or gripping force. If the subjects differ, they cannot be merged into a single number, nor can conversions not given on the page be performed. If an object in the field is heavier, this does not reverse-modify the specification; a larger specification also does not prove that every grasping method reaches that limit. The tool mass is undetermined; do not write the arm's rated payload as the graspable object mass. The acceptance table retains the original units. Object weights from papers cannot be written as already verified in this line. During acceptance, read the subject first, then the number; if the subjects do not match, split into two lines.
Dimensions and scale. Model RMC-AIDAL. Stowed dimensions 640 × 450 × 1780 mm. Chassis 640 × 450 × 250 mm. This row describes form factor or structural scale, used to check doors, elevators, tabletops, or transport — it is not operating height, nor is it arm reach. Do not add it to the vertical range. If the diagram shows protrusions, antennas, or human positioning not present in this row, note separately that they are not part of the specifications. If weight appears in an adjacent row, do not include it in the dimensions sentence. Dimensions from the paper platform cannot replace this row. Doors, elevators, and transport only check form factor; do not treat this row as operating height.
Operating range. Lifting stroke 900 mm, vertical working range 0–2.4 m (also written as 0–2400 mm in the table). Single-arm reach 633 mm. Single-side overhang beyond the chassis 790 mm; the original text does not specify a unit at this point, and since it appears alongside millimeters in the same sentence, write it externally as 790 mm and retain this note. This row describes the range that the hand or lift can reach; the definitions must follow the original sentence: vertical working range, reach, motion radius, or stroke — these cannot be added together or renamed. If "excluding end effector" is stated, it must remain in the figure caption. When the original text does not specify a unit, retain the "unit not specified" note and do not delete it for the sake of tidiness. The workspace definition in the paper cannot replace the definition in this row. The figure caption must retain the range definition from the original sentence, as well as the phrases "excluding end effector" or "unit not specified."
Motion. Two-wheel differential drive, speed 1.5 m/s, slope climbing 5°. Positioning accuracy ±10 mm / ±3°. This line describes how the ground or the main arm moves. Four-wheel steering, four-wheel drive, differential drive, in-place rotation radius, and rotational speed are terms for different mechanisms and cannot substitute for one another. The published speed is a capability, not a recommended teaching speed; teaching may be slower, but a slower speed is written under experimental conditions and is not written back as a specification. For a page that does not state slope climbing or positioning, do not borrow from another page. Whether mobile manipulation is feasible is determined first by whether this line includes ground motion, not by whether a paper used a mobile base. The teaching speed may be lower, but a lower speed is written under the operating conditions and does not change the published capability in this line.
Power. The battery is lithium iron phosphate DC 48V 20Ah. This material dated 2026-08-03 does not state battery life in hours. Do not fill in approximately 6 hours, and do not rewrite it as 48V 31Ah or approximately 4 hours. This line retains only the electrical terms that appear on the page: voltage, capacity, battery life, charging, current, or power. If there are no "hours," write "battery life not given"; do not fill in the blank with hours from an adjacent page. Do not rename charging time as battery life. Rated and maximum values must be listed separately. Retain "approximately" for approximate values. Do not sum the amp-hours of multiple devices and state it as the battery of a single unit. Papers do not provide the battery life for this line. Hours, charging, or current that do not appear remain "not given" and are not copied in from an adjacent page.
Perception and computing. The main controller is Nvidia Jetson AGX Orin 64G, with an additional 1T solid-state drive. Standard vision configuration is D435 ×1, wide-angle cameras ×2, voice module ×1. If the cover states 3 depth channels plus 2 wide-angle channels, this conflicts with the list; the specification follows the list. D435 line: ideal ranging 0.3–3 m; depth ≤1280×720, ≤90 fps; RGB 1920×1080, 30 fps; field of view 69°×42°; rolling shutter. Navigation separately lists depth camera ×1, IMU + encoder ×1, LiDAR ×1, safety edge ×1, ultrasonic ×2. This line inventories the items explicitly stated in sensors, computing, or communications, and retains the words "standard," "standard configuration," "optional," and "recommended." An optional item that is not checked does not count. When the cover conflicts with the list, cite the list while not pretending the cover sentence does not exist. Head-mounted devices and gloves do not enter this line. Processors, drive capacities, or camera channel counts that are not written out must not be drawn into the system diagram. The number of cameras in a paper is not the channel count for this line. Optional sensors that were not purchased do not enter this data dictionary.
End-effector. The recommended configuration lists grippers CTAG2F90-D ×2. The standard configuration quantity table does not include grippers. RMG22-65 is a separate product page. This line states where contact or gripping occurs. Quick-change, compatible, and recommended are not models already in the box. The finger-ring fixture on the main arm is not an end-effector gripper. Force, stroke, and payload are each retained as-is on their respective lines; they are not merged into a single system metric because they are mounted on a particular body. Flanges and protocol mappings that are not given are written as "to be confirmed," not as "plug and play." Grippers from papers are not end-effectors already delivered in this line. "Supports" or "compatible" without a model number cannot be treated as delivered.
Boundary. The standard configuration robotic arm is listed as RM65-B-V ×2, while the robotic arm parameter table lists the model as RM75-B-V. Both model numbers are retained and must be locked before placing the order; do not collapse them into one. This row is a deliberately separated boundary on the page: a different model, a different column, a different product page, or an interface that still requires project confirmation after modularization. The boundary is not a defect note; it is to prevent verbally purchasing two pages as one. When writing the solution, copy the boundary into "not included in this order." If an excluded device is added later, open a new configuration sheet rather than retroactively changing the robot name in the old sample. The embodied difference is precisely the boundary to preserve; do not delete it for the sake of "unification." Devices within the boundary require a separate order; do not rename the old sample to imply it already includes them.
Configuration column. The recommended configuration is RM75-B-V ×2, two-wheel differential chassis ×1, gripper CTAG2F90-D ×2. Teleoperation options are servo teleoperation, backpack teleoperation, and mobile teleoperation, which are not included in the standard configuration quantity table. This row distinguishes standard, recommended, and optional. Recommended and optional items are not delivered unless checked. When the standard row and the parameter table row disagree, keep both rows and use "locked for this order" to indicate which one is actually delivered, rather than striking out one row in the order without signing off. Prices and lead times are not written into this row's paraphrase. Unchecked configurations cannot be described as the same system as in the paper. Unchecked recommended and optional items are written on the order as not delivered.
Excerptable. The following may be copied into an appendix: RMC-AIDAL; 640×450×1780 mm; approximately 80 kg; lift 900 mm; vertical 0–2.4 m; reach 633 mm; rated 5 kg; self-weight 8 kg; repeatability ±0.05 mm; differential drive 1.5 m/s; slope climbing 5°; positioning ±10 mm / ±3°; Orin 64G + 1T SSD; lithium iron phosphate DC 48V 20Ah, hours not given. This is the type of line that can be pasted into an appendix: it has a subject, has units, and can be traced back to the original sentence on the product page. When pasting, retain the words "approximately," "not included," "not given," "optional," and "recommended." Do not convert units and keep only the result. If the same number has different meanings on two pages, write it as two lines in the appendix. Do not mix test protocols into specification excerpts. A proposal may state the source of a question, but must not state a paper's success rate. When pasting into the appendix, paste the words "approximately," "not included," and "optional" along with the numbers.
Do not write. Do not write 17 degrees of freedom for the whole machine, 650×512×1700 mm, approximately 120 kg, lifting 0.3 m, vertical 0–2.1 m, or speed 0.1–1.0 m/s. Do not write 8 kg as the rated payload. Do not write battery life in hours. This line is a negative statement for review purposes. It does not describe what the equipment can do; it only prevents hours, degrees of freedom, payload subjects, or cover slogans from an adjacent page from being written in. If a negative statement is hit, revert to the original sentence on the product page; do not interpret it as "close enough." Success rates from external papers and total hours not published on this site must likewise not be written in. Sentences of the form "using the system from that paper" are prohibited. If a manuscript search hits a negative statement, revert to the original sentence on the product page.
| Projects | Public-Facing Positioning of This Page |
|---|---|
| Degrees of Freedom | In the robotic arm parameter table, model RM75-B-V has 7 degrees of freedom per arm. The product page does not publish the total degrees of freedom for the whole unit; do not fill in 17 or 20. |
| Load and Mass | Single-arm rated payload 5 kg. The 8 kg in the parameter table is the single-arm self-weight. The cover previously stated a dual-arm rated payload of 8 kg, which conflicted with the parameter table; the parameter table takes precedence. The total unit weight of approximately 80 kg is the overall mass. |
| Form Factor and Scale | Model RMC-AIDAL. Folded dimensions 640 × 450 × 1780 mm. Chassis 640 × 450 × 250 mm. |
| Operating Range | Lifting stroke 900 mm, vertical working range 0–2.4 m (also written as 0–2400 mm in the table). Single-arm reach 633 mm. Single-side overhang beyond the chassis is 790 mm; the original text did not specify a unit at that point, but since it appears alongside millimeters in the same sentence, it is written externally as 790 mm with this note retained. |
| Motion | Two-wheel differential drive, speed 1.5 m/s, climbing slope 5°. Positioning accuracy ±10 mm / ±3°. |
| Power | The battery is lithium iron phosphate DC 48V 20Ah. This document dated 2026-08-03 does not state battery life in hours. Do not add approximately 6 hours, and do not rewrite it as 48V 31Ah or approximately 4 hours. |
| Perception & Compute | Main controller Nvidia Jetson AGX Orin 64G, with an additional 1T solid-state drive. Standard vision configuration is D435 ×1, wide-angle cameras ×2, voice module ×1. If the cover states 3 depth channels plus 2 wide-angle channels, this conflicts with the list; the specifications follow the list. D435 row: ideal ranging 0.3–3 m; depth ≤1280×720, ≤90 fps; RGB 1920×1080, 30 fps; field of view 69°×42°; rolling shutter. Navigation separately lists depth camera ×1, IMU + encoder ×1, LiDAR ×1, safety edge ×1, ultrasonic ×2. |
| End Effector | The recommended configuration lists gripper CTAG2F90-D ×2. The standard configuration quantity table does not include a gripper. RMG22-65 is a separate product page. |
| Boundary | The standard configuration lists the robotic arm as RM65-B-V ×2, while the robotic arm parameter table lists the model as RM75-B-V. Both model numbers are retained; lock one before placing the order — do not collapse them into a single number. |
| Configuration Panel | Recommended configuration is RM75-B-V ×2, two-wheel differential chassis ×1, gripper CTAG2F90-D ×2. Teleoperation options are servo teleoperation, backpack teleoperation, and mobile teleoperation; these are not included in the standard configuration quantity table. |
| Excerptable | Attachment copy: RMC-AIDAL; 640×450×1780 mm; approximately 80 kg; lifting 900 mm; vertical 0–2.4 m; reach 633 mm; rated 5 kg; self-weight 8 kg; repeatability ±0.05 mm; differential drive 1.5 m/s; slope climbing 5°; positioning ±10 mm / ±3°; Orin 64G + 1T SSD; lithium iron phosphate DC 48V 20Ah, hours not specified. |
| Do not write | Do not write 17 degrees of freedom for the whole unit, and do not write 650×512×1700 mm, approximately 120 kg, lifting 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Do not write 8 kg as the rated payload. Do not write battery life in hours. |

Relationship to Public Methods and Adjacent Pages
Placing the product in the literature is to illustrate what data capture problems look like, not to borrow the paper's experimental conclusions. Public works that can be explicitly cited include: dual-arm master-slave teleoperation and action-chunked imitation learning as represented by ALOHA; mobile dual-arm demonstration as represented by Mobile ALOHA; learning visuomotor policies from demonstrations as represented by Diffusion Policy; handheld gripper capture as represented by UMI, which is deliberately not a full robot; and cross-robot data aggregation as represented by Open X-Embodiment, provided the embodiment is labeled.
These works each use their own robots, tasks, and success definitions. TOBI did not participate in those experiments. This article does not transcribe their success rates, number of data records, or dollar costs. When readers need those figures, they should read the original papers.
What is useful for this product is only the checklist: whether the action space matches the slave end, which camera the observation comes from, whether the chassis moves, whether end-effector open/close is in the action vector, whether timestamps are aligned, and whether the robot unit identifier is written into the samples. Items on the checklist that the product page does not answer remain unanswered.
This article uses the literature to lay out the questions, then answers the ones that can be answered using the product's public specifications.
Before handing off to a colleague
When finalizing the literature section, delete all percentages and hours unless the sentence explicitly states "the following figures belong to the original paper and are not measured values of this product", and do not place the figures next to this product's specifications. Only the question list is retained. Questions that can be answered from the product page have their answers rewritten as the original sentences; questions that cannot be answered are left blank. Check the last sentence for an erroneous statement such as "the system adopted from that paper". If such a sentence exists, delete the section rather than adding a footnote to justify it. The literature section is limited to one page. Exceeding one page usually means experiment details have started to be restated. Delete the experiment details and keep only the questions. Questions are answered with original sentences from the product page or left blank. The footer is fixed with one sentence: the success rates, data scale, and costs of external papers belong to the original authors, are not measured values of this company, and do not constitute a test of the equipment in this document. A literature section without this footer sentence is not published.
First, the literature section should not exceed the question list.
Second, do not copy success rates.
Third, use the original sentence when it can answer the question.
Fourth, leave blank what cannot be answered.
Fifth, delete "adopts the system from that paper."
Sixth, the footer states that the figures belong to the original authors.
