Negative statements are used for review, not for describing the product. For the isomorphic teleoperation kit, search for these first: Do not write "one teleoperation kit, approximately 5 kg, with force feedback." Do not write 30 RPM and 110 RPM as a single rotational speed, and do not write DC24V and DC12V as a single voltage. If a search matches, revert to the original sentence on the product page; do not interpret it as "close enough."
Prohibited mixed writing
Other frequent cross-page errors include: merging the three-column kit into a single unit, writing 130 N, 65 mm, 5 kg, and 2 kg as one number, writing charging time as battery life, writing the number of cover camera channels as the standard list, and collapsing RM65-B-V and RM75-B-V into a single model number.
External brand logos do not appear. Success rates from external papers do not appear. The total hours of the data marketplace do not appear, because what the current homepage publicly shows are scenarios, samples, fields, quality notes, and licensing — not an hour count.
There is only one replacement principle: replace with the original sentence from /product-teleop-kit.html. If the original sentence does not state a capability, write "not given on the page."

How to Use This Page in This Version
The review checklist applies to the isomorphic teleoperation kit, not to "common industry usage." Step one: search for these sentences: Do not write "one teleoperation kit, approximately 5 kg, with force feedback." Do not write 30 RPM and 110 RPM as a single rotational speed, and do not write DC24V and DC12V as a single voltage. If a search matches, replace with the original sentence from /product-teleop-kit.html. Step two: search for high-frequency cross-page terms: 6 hours, 17 degrees of freedom, dual-arm rated 8 kg, 3 depth channels, one kit, force feedback across the full lineup, 2 hours of battery life, 130 newtons equals 5 kilograms. These terms may only be retained if they genuinely appear in the original sentences on this page.
Step three: search for brands and papers. External whole-machine brand logos do not appear. Paper success rates, USD costs, and data counts do not appear. Hour totals not published on the homepage do not appear. Human egocentric video is not labeled as robot motion.
Step four: search for combined terms: "comprehensive parameters", "full-series configuration", "standard configuration includes main arm and gripper", "system accuracy". None of these terms appears as a specification row on any of the five cards. If they appear in the manuscript, break them back into the original sentences from each page, or delete them.
After replacing, read through the data dictionary and contract annex again. If the two are still inconsistent, update the dictionary and annex to match the product page, not the other way around. Copy the annex column by column; do not merge. Example: GLN-RX75, force feedback supported, 709 mm, 7.8 kg, handle, ±0.003°, 30 RPM, integrated joint, RJ45, DC24V, ≤200 W.
Line-by-Line Verification
Degrees of freedom. All three columns have 7 degrees of freedom; this does not mean they can be merged into one unit. The column names are GLN-RX75, GLN-RX71, and local isomorphic kit. This row only states the number and locations of joints that have already been published. It does not evaluate intelligence, and it does not automatically include the waist, legs, neck, or a whole-body total that is not named on the page. When writing into an action vector, create channels only for the body parts named in this row; body parts not named remain blank. Do not write blank as 0, because 0 would be treated by training scripts as a real angle. Do not fill in the integer degrees of freedom from another device to make this row add up. If the master-follower joint order is not given on the page, mark it as pending written configuration confirmation; do not number it yourself. During review, search for incorrect whole-body degrees of freedom. The action vector creates channels only for the body parts named in this row; unnamed body parts remain blank and are not filled with 0.
Payload and mass. Master arm self-weight: 7.8 kg for GLN-RX75, 3.8 kg for GLN-RX71, and approximately 1.5 kg for the local isomorphic kit (including gripper). Self-weight is not the follower-side rated payload. The numbers in this row must be read with their subjects: rated, self-weight, whole-unit mass, envelope, friction, or gripping force. If the subjects differ, they cannot be merged into a single number, nor can conversions not given on the page be performed. If an object in the field is heavier, this does not retroactively change the specification; a larger specification does not prove that every grasping method reaches that limit. If the tool mass is undetermined, do not write the arm's rated value as the graspable object mass. The acceptance sheet retains the original units. During review, search for sentences that write self-weight or gripping force as rated values. During acceptance, read the subject before the number; if the subjects do not match, split into two rows.
Appearance and scale. Motion radius: 709 mm, 474 mm, 599 mm. This is the scale of the main arm, not the appearance of the slave platform. This row describes appearance or structural scale, used to verify doorways, elevators, tabletops, or transport; it is not operating height, nor is it arm reach. Do not add it to the vertical range. If the diagram shows protrusions, antennas, or human standing positions not listed in this row, note separately that they are not part of the specification. If weight appears in an adjacent row, do not write it into the dimension sentence. During review, search for the appearance of another machine. Doorways, elevators, and transport are only checked against appearance; do not treat this row as operating height.
Operating range. Configuration: the first two columns are humanoid configurations; the local column is a follower arm. Gripping: the first two columns use handles; the local column uses a rail-type ring gripper. This row describes the range that the hand or lift can reach. The definitions must follow the original wording: vertical working range, arm span, motion radius, or stroke. These cannot be added together or renamed. If "excluding end effector" is stated, it must remain in the figure caption. If the original text does not specify units, retain the "units not specified" note; do not delete it for the sake of tidiness. During review, search for sentences that add together different range definitions. The figure caption retains the range definitions from the original wording, as well as the terms "excluding end effector" or "units not specified."
Motion. Maximum operating speed: 30 RPM in the first two columns, 110 RPM in the local column. The dragging force column reads zero-force dragging in all three columns. Zero-force dragging is not force feedback. This line describes how the base or main arm moves. Four-wheel steering and four-wheel drive, differential drive, in-place rotation radius, and rotational speed are terms for different mechanisms and cannot be substituted for one another. Published speed is a capability, not a recommended teaching speed; teaching can be slower, but a slower speed is recorded under experimental conditions and is not written back as a specification. Do not borrow slope climbing or positioning figures from other pages if the page does not list them. During review, search for sentences that mix up differential drive, four-wheel steering and four-wheel drive, and rotational speed. Teaching speed can be lower, but the lower value is recorded under operating conditions and does not change the published capability in this line.
Power. Operating voltage: the first two columns are DC24V, the local column is DC12V. Power: ≤200 W, ≤100 W, rated 84 W. The specification table has no battery row, so do not write endurance. This row keeps only the electrical terms that appear on the page: voltage, capacity, endurance, charging, current, or power. If there is no "hours," write that endurance is not given; do not fill the gap with hours from an adjacent page. Do not rename charging time as endurance. Rated and maximum values must be listed in separate columns. Keep "approximately" where an approximate value is given. Do not sum the ampere-hours of multiple devices and state them as the battery of a single device. During review, search for the 6 hours that was borrowed and the charging time that was written as endurance. Hours, charging, or current that do not appear should remain as not given and must not be copied in from an adjacent page.
Sensing and computing. Angular resolution: ±0.003° for the first two columns, 0.088° for the local column. Motors: integrated joints for the first two columns, bus servos for the local column. Communication: RJ45 for the first two columns, RJ45 / 10-pin aviation connector for the local column. This row lists the items already specified in sensing, computing, or communication, and retains the terms standard, included as standard, optional, and optional accessory. An optional item that is not checked does not count. If the cover conflicts with the list, cite the list, but do not pretend the cover statement does not exist. Headsets and gloves do not enter this row. Do not draw processors, hard drive capacity, or camera channel counts into the system diagram if they are not specified. During review, search for cover channel counts written as standard deliverables. Optional sensors that have not been purchased do not enter this data dictionary.
End. The fixture listed under the local column is a rail-type finger-ring fixture, used to hold the main arm, not the RMG22-65 at the end. The end gripper is ordered separately. This line states which end the contact or gripping occurs at. Quick-change, compatible, and recommended are not models already in the box. The finger-ring fixture on the main arm is not the end gripper. Force, stroke, and payload remain as-is on their respective lines and are not merged into a single system metric because they are mounted on a particular robotic platform. Flange and protocol mappings that are not provided should be written as "to be confirmed," not as "plug and play." During review, search for cases where an unordered gripper is written as included. "Supports" or "compatible" without a model number cannot be treated as delivered.
Boundary. Force feedback is only listed as supported for GLN-RX75 and GLN-RX71. The local isomorphic suite is listed as not supported. The main arm models are RX75, RX71, YDS-DAP-75/65/RX75S. This line is a deliberately separated boundary on the page: another model, another column, another product page, or an interface that still requires project confirmation after modularization. The boundary is not a defect note; it prevents verbally buying two pages as one. When writing a proposal, copy the boundary into "not included in this scope." If a device not included is later added, open a new configuration order rather than retroactively changing the robotic platform name in old samples. During review, search for cases where the two models were collapsed into one. Devices within the boundary require a separate order; do not rename old samples to imply they are already included.
Configuration column. The contract must specify column names. Buying the platform does not by default include the kit. For remote operation, look at the first two columns; for local data collection, look at the third column; in either case, place the order by cell. This row distinguishes standard, recommended, and optional items. Recommended and optional items are not delivered unless checked. When the standard row and the parameter table row are inconsistent, keep both rows and use "locked for this order" to indicate which one is actually delivered, rather than striking out one row in the order without sign-off. Price and lead time are not written into this row's restatement. During review, search for recommended items written as standard. Unchecked recommended and optional items are written as not delivered on the order.
Excerptable. Copy the attachment column by column; do not merge. Example: GLN-RX75, force feedback supported, 709 mm, 7.8 kg, handle, ±0.003°, 30 RPM, integrated joint, RJ45, DC24V, ≤200 W. This row defines the type of content that can be pasted into the attachment: with a subject, with units, and traceable to the original sentence on the product page. When pasting, retain "approximately," "not included," "not given," "optional accessory," and "recommended." Do not convert and keep only the result. If the same number has different meanings on two pages, write it as two rows in the attachment. Do not mix test protocols into specification excerpts. During review, confirm that the attachment has not lost the original rows after conversion. When pasting into the attachment, paste the words "approximately," "not included," and "optional accessory" along with the content.
Do not write. Do not write "one teleoperation kit, approximately 5 kg, with force feedback." Do not write 30 RPM and 110 RPM as a single rotational speed, and do not write DC24V and DC12V as a single voltage. This row consists of negative statements for review purposes. It does not describe what the equipment can do; it only prevents hours from an adjacent page, degrees of freedom, payload subjects, or cover slogans from being written in. If a negative statement is matched, revert to the original sentence on the product page; do not interpret it as "close enough." Do not write in success rates from external papers or total hours not published on this site. Negative statements themselves do not enter marketing slogans. If a manuscript search matches a negative statement, revert to the original sentence on the product page.
| Projects | Public-Facing Positioning of This Page |
|---|---|
| Degrees of Freedom | All three columns have 7 degrees of freedom, but this does not mean they can be merged into a single unit. The column names are GLN-RX75, GLN-RX71, and local isomorphic kit. |
| Load and Mass | Main arm self-weight: GLN-RX75 is 7.8 kg, GLN-RX71 is 3.8 kg, the local isomorphic kit is approximately 1.5 kg (including the fixture). Self-weight is not the rated payload at the end-effector. |
| Form Factor and Scale | Working radius: 709 mm, 474 mm, 599 mm. These are the dimensions of the main arm, not the outline of the end unit. |
| Operating Range | Configuration: the first two columns are anthropomorphic configurations; the local column is the same as the follower arm. Gripping: the first two columns use handles; the local column uses a rail-mounted finger-ring fixture. |
| Motion | Maximum operating speed: the first two columns are 30 RPM, the local column is 110 RPM. All three columns list zero-force gravity compensation. Zero-force gravity compensation is not force feedback. |
| Power | Operating voltage: the first two columns are DC24V, the local column is DC12V. Power: ≤200 W, ≤100 W, rated 84 W. The specification table has no battery row, so do not state battery life. |
| Perception & Compute | Angular resolution: the first two columns are ±0.003°, the local column is 0.088°. Motor: the first two columns use integrated joints, the local column uses bus servos. Communication: the first two columns use RJ45, the local column uses RJ45 / 10-pin aviation connector. |
| End Effector | The fixture in the local column is a rail-type ring fixture used to hold the main arm; it is not the RMG22-65 end-effector. The end-effector gripper is ordered separately. |
| Boundary | Force feedback is listed as supported only for GLN-RX75 and GLN-RX71. The local isomorphic kit is listed as not supported. The main arm models are RX75, RX71, and YDS-DAP-75/65/RX75S. |
| Configuration Panel | The contract must specify column names. Purchasing the platform does not include the kit by default. For remote operation, refer to the first two columns; for local data capture, refer to the third column; in either case, order by the individual cell. |
| Excerptable | Transcribe the attachments column by column; do not merge. Example: GLN-RX75, force feedback supported, 709 mm, 7.8 kg, handle, ±0.003°, 30 RPM, integrated joint, RJ45, DC24V, ≤200 W. |
| Do not write | Do not write "one teleoperation kit, approximately 5 kg, with force feedback." Do not write 30 RPM and 110 RPM as a single speed, and do not write DC24V and DC12V as a single voltage. |

Relationship to Public Methods and Adjacent Pages
Prohibiting mixed writing is both an editorial rule and a delivery rule. The following sentences have already caused or are prone to cause misunderstanding in the product copy on this site, and new articles will no longer use them.
Do not attribute the approximately 6 hours of the folding model to the lift model. Do not describe the lift model as having 17 degrees of freedom for the whole machine, nor as 650×512×1700 mm, approximately 120 kg, lifting 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Those figures belong to a different publicly documented machine, not to this RMC-AIDAL page. Do not write the arm's self-weight of 8 kg as the dual-arm rated payload. Do not merge RM65-B-V from the standard list and RM75-B-V from the arm table into a single model number. Do not write the cover's "3 depth + 2 wide-angle" as delivered; the standard vision configuration is one D435 depth camera plus two wide-angle cameras. Do not write the left/right extension of 790 as a bare number without units, nor pretend the original text printed a unit.
Do not merge the kit's three columns into one machine, and do not write force feedback for the local column. Do not write RMG22-65's 130 N, 65 mm, 5 kg, and 2 kg as the same "5." Do not write the wheeled humanoid's 40 Ah battery and approximately 2-hour charge time as 2-hour endurance. Do not cite brand logos that do not appear on this site. Do not write external paper success rates as TOBI measured results.
This article uses the three sentences most commonly written incorrectly for this product as counterexamples and provides replacement sentences.
Before handing off to a colleague
Review uses search, not full reading. Create a search table of negative sentences and high-frequency cross-page terms, and run it once each against the article, attachments, and data dictionary. On a hit, replace; do not add "basically consistent" next to it. The search table also includes external brand identifiers and paper success rates. After replacement, sample three rows of numbers and go back to the product page to verify the subject. If the subject is wrong, even if the number matches, it counts as a hit. The review record retains the search terms and the original sentences after replacement. The search table goes into the version repository and is committed together with the article. Changing only the article without updating the search record counts as an incomplete review. The search record logs hit counts. A zero hit count must also be recorded, showing the search was run. The three sampled rows must state the subject and the product page location. If the subject check fails, the entire article is rejected, not just those three rows, because errors of this kind usually occur in more than one place.
First, submit the retrieval table together with the article.
Second, record even if the hit count is zero.
Third, spot-check three rows to verify the subject.
Fourth, if the subject fails, the entire document is returned.
Fifth, the same number with a different subject still counts as a match.
Sixth, do not write "basically consistent" next to a hit. After retrieval is complete, the list of hit terms is appended to the internal record at the end of the document, not to the public page. The public page retains only the original sentence after replacement. The internal record is used for the next review, not for external promotion.
