Prohibited sentences are used for proofreading, not for describing the product. For a wheeled humanoid teleoperation body, search for these first: Do not write "charging approximately 2 hours" as "battery life 2 hours." Do not write the folding version's 20 DoF or approximately 6 hours onto this unit. Do not write the lift version's 900 mm as this unit's lift stroke. If a search hit is found, revert to the original sentence on the product page; do not explain it as "close enough."
Prohibited mixed writing
Other frequent cross-page errors include: merging the three-column kit into a single unit, writing 130 N, 65 mm, 5 kg, and 2 kg as one number, writing charging time as battery life, writing the number of cover camera channels as the standard list, and collapsing RM65-B-V and RM75-B-V into a single model number.
External brand logos do not appear. Success rates from external papers do not appear. The total hours of the data marketplace do not appear, because what the current homepage publicly shows are scenarios, samples, fields, quality notes, and licensing — not an hour count.
There is only one replacement principle: replace with the original sentence from /product-body-humanoid.html. For any capability not stated on that page, write "not provided on the page."

How to Use This Page in This Version
The review checklist applies to the wheeled humanoid teleoperation robotic platform, not to "common industry usage." Step one: search for these sentences: Do not write "approximately 2 hours of charging" as "2 hours of battery life." Do not write the 20 DoF or approximately 6 hours of the folding model onto this unit. Do not write the 900 mm of the lift model as this unit's lift travel. If a hit is found, replace it with the original sentence from /product-body-humanoid.html. Step two: search for cross-page high-frequency terms: 6 hours, 17 degrees of freedom, dual-arm rated 8 kg, 3-channel depth, one kit, force feedback across the full lineup, 2 hours of battery life, 130 newtons equals 5 kilograms. These terms may only remain if they genuinely appear in the original sentences on this page.
Step three: search for brands and papers. External whole-machine brand logos do not appear. Paper success rates, USD costs, and data counts do not appear. Hour totals not published on the homepage do not appear. Human egocentric video is not labeled as robot motion.
Step four: search for combined terms: "comprehensive parameters", "full-series configuration", "standard configuration includes main arm and gripper", "system accuracy". None of these terms appears as a specification row on any of the five cards. If they appear in the manuscript, break them back into the original sentences from each page, or delete them.
After making replacements, re-read the data dictionary and contract attachment. If the two are still inconsistent, correct the dictionary and attachment based on the product page, rather than changing the page to accommodate the manuscript. The attachment may copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; charging approximately 2 hours.
Line-by-Line Verification
Degrees of freedom. The total active degrees of freedom for the whole body is 21, broken down as: dual arms 14, waist 3, legs 2, neck 2. This row only states the number of joints and body parts that have been publicly disclosed. It does not evaluate intelligence, and it does not automatically include the waist, legs, neck, or whole-body total that are not explicitly named on the page. When writing the action vector, only create channels for the body parts named in this row; body parts not named remain blank. Do not write blanks as 0, because 0 will be treated by the training script as a real angle. Do not fill in the degrees-of-freedom integer from another device after this row to make the numbers add up. If the master-slave joint order is not given on the page, mark it as pending written configuration confirmation; do not number it yourself. During review, search for incorrect whole-body degrees of freedom. The action vector only creates channels for the body parts named in this row; body parts not named are left blank, not filled with 0.
Load and mass. Single-arm payload: 5 kg. Overall weight: approximately 125 kg, which is not the single-arm payload. Every number in this row must be read together with its subject: rated, self-weight, overall mass, envelope, friction, or gripping force. Numbers with different subjects must not be merged into a single figure, and no conversion not given on the page may be performed. If objects in the field are heavier, the specification must not be revised accordingly; a higher specification does not prove that every grasping method reaches that limit. The tool mass is undetermined, so the arm's rated value must not be written as the graspable object mass. The acceptance table retains the original units. During proofreading, search for sentences that write self-weight or gripping force as rated. During acceptance, read the subject first and then the number; if the subjects differ, split them into two rows.
Appearance and scale. Overall dimensions: 570 × 465 × 1680 mm. The chassis width and shoulder width are kept within 465 mm. This line describes the exterior or structural scale, used to verify doorways, elevators, tabletops, or transport clearance — it is not the operating height, nor the arm span. Do not add it to the vertical range. If the diagram shows protrusions, antennas, or human standing positions not present in this line, note separately that they are not part of the specification. If weight appears in an adjacent row, do not include it in the dimension sentence. During review, search for the exterior of another machine. For doorways, elevators, and transport, only verify the exterior — do not treat this line as the operating height.
Operating range. Vertical reach 2100 mm. Horizontal reach 1818 mm, excluding the end effector. This line describes the range that the hand or lift can reach; the definition must follow the original sentence: vertical working range, reach, motion radius, or stroke. These cannot be added together or renamed. If "excluding the end effector" is stated, it must remain in the figure caption. If the original text does not specify units, retain the "units not specified" note; do not delete it for the sake of tidiness. During review, search for sentences that add together different range definitions. The figure caption retains the range definition from the original sentence, as well as the terms "excluding end" or "units not specified."
Motion. Motion speed 0.1–1.5 m/s. Rotation radius 690 mm, defined as in-place rotation. This line describes how the ground platform or main arm moves. Four-wheel steering, differential drive, in-place rotation radius, and rotational speed are terms for different mechanisms and cannot be substituted for one another. Published speed is a capability, not a recommended teaching speed; teaching can be slower, but a slower speed is recorded under experimental conditions and is not written back into the specification. On pages that do not mention gradeability or positioning, do not borrow from other pages. During review, search for sentences that mix up differential drive, four-wheel steering, and rotational speed. Teaching speed can be lower, but the lower speed is recorded under operating conditions and does not change the published capability in this line.
Power. Battery 40 Ah (BMS). Charging time approximately 2 hours. Approximately 2 hours is charging time, not battery life; the page does not state battery life in hours. This line should only retain electrical terms that appear on the page: voltage, capacity, battery life, charging, current, or power. If there is no "hours", write "battery life not specified" — do not fill in the blank with hours from an adjacent page. Do not rename charging time as battery life. Rated and maximum values must be listed separately. Preserve "approximately" for approximate values. Do not sum amp-hours across multiple devices and present the total as one device's battery. During proofreading, search for the borrowed 6 hours and charging times written as battery life. Hours, charging, or current that do not appear should remain as "not specified" and must not be copied in from an adjacent page.
Perception and computing. The vision system is listed as binocular depth / RGB optional. Wide-angle cameras: 130° FOV × 3, located at the chest / back / chassis. The LiDAR is a single-line laser with a detection range greater than 40 m (reflectivity 90%). The voice interaction module is a ring of 6 microphones, optional. Depth camera versions: data acquisition edition Aobi 335LG; standard edition Intel RealSense D405; optional Intel RealSense D435. This line itemizes the items explicitly stated in sensing, computing, or communications, and retains the terms standard, included as standard, optional, and optional configuration. An optional item that is not checked does not count. When the cover conflicts with the specification list, cite the list, but do not pretend the cover statement does not exist. Headsets and gloves do not belong in this line. Do not draw processors, hard drive capacity, or camera channel counts that are not stated into the system diagram. During review, search for cover channel counts being written as standard delivery. Optional sensors that have not been purchased do not enter this data dictionary.
End effector. A multi-degree-of-freedom dexterous hand or gripper can be added to the end according to the task. The page states compatibility with grippers and dexterous hands from Aoyi, BrainCo, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard configuration list. This line describes where contact or gripping occurs. Quick-change, compatible, and recommended are not models already in the box. The ring fixture on the main arm is not an end-effector gripper. Force, stroke, and payload remain as stated in their respective lines and are not merged into a single system metric just because they are mounted on a particular body. For flange and protocol mappings that are not provided, write "to be confirmed," not "plug and play." During review, search for grippers that have not been ordered being written as included. "Supports" or "compatible" without a model number cannot be treated as delivered.
Boundary. The upper body and wheeled chassis are a modular structure. How to connect to other chassis after separation is subject to project interface confirmation and must not be written in the public specification as already connected. This line is a boundary deliberately separated on the page: another model, another column, another product page, or an interface that still requires project confirmation after modularization. The boundary is not a defect note; it prevents verbally buying two pages as one. When writing a solution, copy the boundary into "not included in this order." If a device not included is added later, open a new configuration sheet; do not go back and change the body name in the old sample. During review, search for two models being collapsed into one. Devices within the boundary must be ordered separately; do not rename the old sample to say it already includes them.
Configuration column. The voice module and depth camera versions both have optional rows. Optional items are not written into the delivery unless checked. The end-effector brand must be named in the configuration sheet; do not write "compatible means included." This line distinguishes standard, recommended, and optional. Recommended and optional items are not delivered unless checked. When the standard row conflicts with the parameter table row, keep both rows and use "locked for this order" to indicate which one is actually delivered, rather than crossing out one row in the order without signing off. Prices and lead times are not written into this line's restatement. During review, search for recommended items being written as standard. Unchecked recommended and optional items are written as not delivered on the order.
Excerptable. The following can be copied into an appendix: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; charging approximately 2 hours. This line is the type that can be pasted into an appendix: with a subject, with units, and traceable back to the original sentence on the product page. When pasting, retain "approximately," "excluding," "not provided," "optional configuration," and "recommended." Do not convert and keep only the result. If the same number has different meanings on two pages, write it as two lines in the appendix. Test protocols must not be mixed into specification excerpts. During review, confirm the appendix has not lost the original line after conversion. When pasting into the appendix, paste the words "approximately," "excluding," and "optional configuration" along with the numbers.
Do not write. Do not write "charging approximately 2 hours" as "battery life 2 hours." Do not write the foldable model's 20 DoF or approximately 6 hours onto this device. Do not write the lift model's 900 mm as this device's lift travel. This line is a negative sentence for editorial review. It does not describe what the device can do; it only prevents writing in hours, degrees of freedom, load subjects, or cover slogans from adjacent pages. If a negative sentence is hit, revert to the original product page sentence and do not interpret it as "close enough." Do not write in external papers' success rates or total hours not publicly disclosed on this site. The negative sentence itself does not enter promotional slogans. If manuscript retrieval hits a negative sentence, revert to the original product page sentence.
| Projects | Public-Facing Positioning of This Page |
|---|---|
| Degrees of Freedom | Total active degrees of freedom: 21, broken down as dual arms 14, waist 3, legs 2, neck 2. |
| Load and Mass | Single-arm payload 5 kg. Total unit weight is approximately 125 kg, which is not the single-arm payload. |
| Form Factor and Scale | Overall dimensions 570 × 465 × 1680 mm. The chassis width and shoulder width are kept within 465 mm. |
| Operating Range | Vertical reach 2100 mm. Horizontal reach 1818 mm, excluding the end effector. |
| Motion | Motion speed 0.1–1.5 m/s. Turning radius 690 mm; the specification refers to in-place rotation. |
| Power | Battery 40 Ah (BMS). Charging time approximately 2 hours. The approximately 2 hours refers to charging, not runtime; the page does not state runtime in hours. |
| Perception & Compute | The vision system is listed as binocular depth / RGB optional. Wide-angle camera 130° FOV ×3, located on the chest / back / chassis. The LiDAR is a single-line laser with detection range greater than 40 m (90% reflectivity). The voice interaction module is a ring-shaped 6-microphone array, optional. Depth camera versions: data collection version Orbbec 335LG; standard version Intel RealSense D405; optional Intel RealSense D435. |
| End Effector | A multi-degree-of-freedom dexterous hand or gripper can be added to the end effector depending on the task. The page explicitly states compatibility with grippers and dexterous hands from Aoyi, Qiangnao, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard configuration list. |
| Boundary | The upper body and wheeled chassis are modular. How to connect to other chassis after separation must be confirmed per the project interface; do not state in the public table that it is already connected. |
| Configuration Panel | Both the voice module and depth camera versions have optional rows. Optional items are not included in unchecked deliveries. The end-effector brand must be specified by name in the configuration sheet; do not write "compatible means already included." |
| Excerptable | Attachment copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm maximum width; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end-effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; approximately 2 hours of charging. |
| Do not write | Do not write "approximately 2 hours of charging" as "2 hours of battery life." Do not attribute the folding model's 20 DoF or approximately 6 hours of battery life to this unit. Do not write the lifting model's 900 mm as this unit's lifting stroke. |

Relationship to Public Methods and Adjacent Pages
Prohibiting mixed writing is both an editorial rule and a delivery rule. The following sentences have already caused or are prone to cause misunderstanding in the product copy on this site, and new articles will no longer use them.
Do not attribute the approximately 6 hours of the folding model to the lift model. Do not describe the lift model as having 17 degrees of freedom for the whole machine, nor as 650×512×1700 mm, approximately 120 kg, lifting 0.3 m, vertical 0–2.1 m, speed 0.1–1.0 m/s. Those figures belong to a different publicly documented machine, not to this RMC-AIDAL page. Do not write the arm's self-weight of 8 kg as the dual-arm rated payload. Do not merge RM65-B-V from the standard list and RM75-B-V from the arm table into a single model number. Do not write the cover's "3 depth + 2 wide-angle" as delivered; the standard vision configuration is one D435 depth camera plus two wide-angle cameras. Do not write the left/right extension of 790 as a bare number without units, nor pretend the original text printed a unit.
Do not merge the kit's three columns into one machine, and do not write force feedback for the local column. Do not write RMG22-65's 130 N, 65 mm, 5 kg, and 2 kg as the same "5." Do not write the wheeled humanoid's 40 Ah battery and approximately 2-hour charge time as 2-hour endurance. Do not cite brand logos that do not appear on this site. Do not write external paper success rates as TOBI measured results.
This article uses the three sentences most commonly written incorrectly for this product as counterexamples and provides replacement sentences.
Before handing off to a colleague
Review uses search, not full reading. Create a search table of negative sentences and high-frequency cross-page terms, and run it once each against the article, attachments, and data dictionary. On a hit, replace; do not add "basically consistent" next to it. The search table also includes external brand identifiers and paper success rates. After replacement, sample three rows of numbers and go back to the product page to verify the subject. If the subject is wrong, even if the number matches, it counts as a hit. The review record retains the search terms and the original sentences after replacement. The search table goes into the version repository and is committed together with the article. Changing only the article without updating the search record counts as an incomplete review. The search record logs hit counts. A zero hit count must also be recorded, showing the search was run. The three sampled rows must state the subject and the product page location. If the subject check fails, the entire article is rejected, not just those three rows, because errors of this kind usually occur in more than one place.
First, submit the retrieval table together with the article.
Second, record even if the hit count is zero.
Third, spot-check three rows to verify the subject.
Fourth, if the subject fails, the entire document is returned.
Fifth, the same number with a different subject still counts as a match.
Sixth, do not write "basically consistent" next to a hit. After retrieval is complete, the list of hit terms is appended to the internal record at the end of the document, not to the public page. The public page retains only the original sentence after replacement. The internal record is used for the next review, not for external promotion.
Continue Reading
- 01 Task Boundaries
- 02 Specification Standards
- 03 Degrees of Freedom
- 04 Payload & Self-Weight
- 05 Workspace
- 06 Locomotion Method
- 07 Perception and Computing
- 08 Power Specifications
- 09 Data Recording
- 10 Time Alignment
- 11 End-Effector Boundaries
- 12 Site Constraints
- 13 Configuration Sheet
- 14 Three-Way Comparison
- 15 Literature References
- 16 Master-Slave Workstation
- 17 Acceptable Deliverable Statements
- 18 Prohibited Conflations
- 19 On-Site Deployment
- 20 Evaluation Path
Back to Product Center View this product page
This article was written on October 3, 2026, for selection and specification verification purposes. Device parameters are subject to the product page tables and do not constitute a supply commitment. External papers only illustrate how problems are framed in the industry; their success rates and data scales belong to the original authors' experiments and are not TOBI's measured results. Phone: +86 137 5502 0164.
