Attachments may only contain sentences that include units, a subject, and can be found at /product-body-humanoid.html. Attachments may copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end effector); in-place turning radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; charging approximately 2 hours. When copying, retain the model number and qualifiers such as "approximately," "excluding end effector," "hours not specified," and "unit not indicated in the original text." These words are part of the sentence.
Acceptable Statements
If the same number appears twice, write two rows. 5 kg can be a single-arm rated load or a gripper envelope. ±0.05 mm can be the arm's repeatability or the gripper's position repeatability. Whether 48V 20Ah is followed by hours depends on which page it comes from.
Recommended and optional sentences go in the latter half of the appendix, each row with a checkbox. Printing unchecked items is safer than not printing them. The voice module and depth camera versions both have optional rows. Optional items are not written into the delivery for unchecked boxes. The end-effector brand must be named in the configuration sheet; do not write "compatible, therefore included."
Exclusion statement goes at the end of the appendix. Do not write "charging approximately 2 hours" as "battery life 2 hours." Do not write the folding version's 20 DoF or approximately 6 hours onto this unit. Do not write the lift version's 900 mm as this unit's lift stroke. A contract without an exclusion statement will by default be filled in with verbal additions.

How to Use This Page in This Version
Use excerpts from the contract attachment, not paraphrases. Excerpt format: table header, original sentence, source path. Attachments may be copied: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; charging approximately 2 hours. All instances of "approximately", "excluding", "hours not given", "unit not specified in the original text", "optional", and "recommended" in the original sentences must be preserved. Removing these words would change the legal meaning of the sentences.
When the same number appears on multiple rows, the appendix also has multiple rows, and the subject is written in the header. Do not perform a unit conversion and keep only the converted result. 130 N is not converted to kilograms to replace the original row. Millimeters are not changed to meters to make the number look smaller, unless both rows are kept.
Checkboxes are used for recommendations and optional items. Both the voice module and depth camera versions have optional rows. Optional items are not included in the deliverables unless checked. The end-effector brand must be specified by name on the configuration sheet; do not write "compatible means already included." Unchecked rows are printed as "not delivered." Exclusions are phrased as affirmative negative statements, derived from: do not write a charge time of approximately 2 hours as a battery life of 2 hours. Do not write the 20 DoF of the folding model or approximately 6 hours onto this unit. Do not write the 900 mm of the height-adjustable model as the lift travel of this unit. Exclusions and order items are printed on separate pages to avoid signing only the front page.
The attachment does not include a pricing formula, does not state "equivalent to a certain paper's platform," and does not include brand logos that do not appear on /product-body-humanoid.html. Additional tests required, such as actual battery life or system repeatability precision, should be written as separate test protocols, not included in the specification excerpt.
Line-by-Line Verification
Degrees of freedom. Total active degrees of freedom: 21, broken down as dual arms 14, waist 3, legs 2, neck 2. This row only states the number of joints and body parts that have already been made public. It does not evaluate intelligence, and it does not automatically include the waist, legs, neck, or whole-machine total that are not named on the page. When writing the action vector, only build channels for body parts present in this row; body parts not present remain blank. Do not write blanks as 0, because 0 would be treated by training scripts as a real angle. Also, do not fill in the integer degrees of freedom from another device after this row to make it add up. If the master-slave joint order is not given on the page, mark it as pending written configuration confirmation rather than numbering it yourself. Paste the original sentence in the attachment's degrees-of-freedom column. The action vector builds channels only for the body parts named in this row; unnamed body parts are left blank, not filled with 0.
Load and mass. Single-arm payload: 5 kg. Overall weight: approximately 125 kg, which is not the single-arm payload. Every number in this row must be read together with its subject: rated, self-weight, overall mass, envelope, friction, or gripping force. Numbers with different subjects must not be merged into a single figure, and no conversion not given on the page may be performed. If objects in the field are heavier, the specification must not be revised accordingly; a higher specification does not prove that every grasping method reaches that limit. The tool mass is undetermined, so the arm's rated value must not be written as the graspable object mass. The acceptance table retains the original units. The appendix load column is split into rows by subject. During acceptance, read the subject first and then the number; if the subjects differ, split them into two rows.
Dimensions and scale. Overall dimensions: 570 × 465 × 1680 mm. The chassis width and shoulder width are kept within 465 mm. This row describes exterior or structural dimensions, used to check doorways, elevators, tabletops, or transport; it is not an operating height and not an arm reach. Do not add it to the vertical range. If the diagram shows protrusions, antennas, or a person's standing position not listed in this row, note separately that they are not part of the specification. If weight appears in an adjacent row, do not write it into the dimension sentence. The appendix dimension column retains the multiplication sign and millimeters. Doorways, elevators, and transport are checked against the exterior only; do not treat this row as an operating height.
Operating range. Vertical arm reach: 2100 mm. Horizontal arm reach: 1818 mm, excluding the end effector. This row describes the range the hand or lift can reach; the definition must follow the original wording: vertical working range, arm reach, motion radius, or stroke. These terms must not be added together or renamed. If "excluding the end effector" is stated, it must remain in the figure caption. If the original text does not specify units, retain the "units not specified" note and do not remove it for tidiness. The appendix range column retains the "excluding the end effector" or "units not specified" note. The figure caption retains the range definition from the original sentence, as well as the terms "excluding the end effector" or "units not specified."
Motion. Motion speed: 0.1–1.5 m/s. Rotation radius: 690 mm, specified as in-place rotation. This row describes how the ground base or main arm moves. Four-wheel steering, four-wheel drive, differential drive, in-place rotation radius, and rotational speed are terms for different mechanisms and must not be substituted for one another. The published speed is a capability, not a recommended teaching speed; teaching may be slower, but a slower speed is recorded under experimental conditions and is not written back as a specification. If the page does not state slope climbing or positioning, do not borrow from another page. The appendix motion column retains the mechanism terms. Teaching speed may be lower, but a lower speed is recorded under operating conditions and does not change the published capability in this row.
Power. Battery: 40 Ah (BMS). Charging time: approximately 2 hours. Approximately 2 hours is charging, not battery life; the page does not give battery life in hours. This row retains only the electrical terms that appear on the page: voltage, capacity, battery life, charging, current, or power. If there are no "hours," write that battery life is not given; do not fill in the blank with hours from an adjacent page. Do not rename charging time as battery life. Rated and maximum values must be listed in separate columns. Retain "approximately" for approximate values. Do not sum the amp-hours of multiple devices and state it as one device's battery. The appendix electrical column does not add hours. Hours, charging, or current that do not appear remain as not given; do not copy them in from an adjacent page.
Perception and computing. The vision system is listed as binocular depth / RGB, optional. Wide-angle cameras: 130° FOV × 3, located at the chest / back / chassis. The LiDAR is a single-line laser with detection range greater than 40 m (reflectivity 90%). The voice interaction module is a ring of 6 microphones, optional. Depth camera versions: data acquisition version Aobi 335LG; standard version Intel RealSense D405; optional Intel RealSense D435. This row lists the items explicitly stated in sensing, computing, or communications, and retains the terms standard, included as standard, optional, and optional accessory. An optional item that is not checked does not count. If the cover conflicts with the list, cite the list while not pretending the cover statement does not exist. Headsets and gloves do not belong in this row. Processors, storage capacity, or camera channel counts not written out must not be drawn into the system diagram. The appendix sensor column distinguishes standard from optional. Optional sensors not purchased do not enter this data dictionary.
End effector. The end effector can be fitted with a multi-degree-of-freedom dexterous hand or gripper depending on the task. The page specifies compatibility with Aoyi, Qiangnao, Zhixing and other grippers and dexterous hands, as well as the RX75, RM75, RM65 robotic arm platforms. Compatibility is not a standard configuration list. This line states where contact or grasping occurs. Quick-change, compatible, and recommended are not models already included in the box. The ring fixture on the main arm is not an end-effector gripper. Force, stroke, and payload remain as written on their respective rows and are not merged into a single system metric because they are mounted on a particular platform. Flange and protocol mappings that are not provided should be written as "to be confirmed", not "plug and play". The accessory end-effector column should either list model and quantity, or state "not included". "Supports" or "compatible" without a model number cannot be treated as delivered.
Boundary. The upper body and wheeled chassis are a modular structure. How the split modules connect to other chassis must be confirmed through the project interface; do not write it in the public table as already connected. This row is a boundary deliberately separated on the page: another model, another column, another product page, or an interface that still requires project confirmation after modularization. The boundary is not a defect statement; it prevents verbally buying two pages as one. When writing a proposal, copy the boundary into "not included in this order." If equipment not included is added later, open a new configuration sheet; do not go back and change the body name in the old sample. The appendix has a "not included" column, sourced from the boundary row. Equipment within the boundary must be ordered separately; do not rename the old sample to say it already includes it.
Configuration column. The voice module and depth camera versions both have optional rows. Optional items are not written into the delivery for unchecked boxes. The end-effector brand must be named in the configuration sheet; do not write "compatible, therefore included." This row distinguishes standard, recommended, and optional. Recommended and optional items are not delivered unless checked. If the standard row conflicts with the parameter table row, keep both rows and use "locked for this order" to indicate which one is actually delivered, rather than striking out one row in the order without signing off. Price and lead time are not written into this row's restatement. The latter half of the appendix consists of checkboxes; unchecked items are printed as not delivered. Unchecked recommended and optional items are written as not delivered on the order.
Excerptable. Attachments may copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; approximately 2 hours charging. This row is of the type that can be pasted into an attachment: it has a subject, includes units, and can be traced back to the original sentence on the product page. When pasting, preserve words such as approximately, excluding, not specified, optional, and recommended. Do not convert units and keep only the result. If the same number has different meanings on two pages, write it as two separate lines in the attachment. Test protocols must not be mixed into specification excerpts. This is the permitted scope for attachment body text. When pasting into an attachment, include words such as approximately, excluding, and optional along with the values.
Do not write. Do not describe a charging time of approximately 2 hours as a battery life of 2 hours. Do not attribute the foldable model's 20 DoF or approximately 6 hours to this unit. Do not describe the lift model's 900 mm as the lift travel of this unit. This line is a negative statement for review purposes. It does not describe what the device can do; it only prevents hours, degrees of freedom, payload subjects, or cover slogans from adjacent pages from being written in. If a negative statement is matched, revert to the original product page sentence and do not interpret it as "approximately." Do not write in success rates from external papers or total hours not published on this site. The last page of the attachment lists negative statements to prevent signing off only on the positive ones. If the manuscript retrieval matches a negative statement, revert to the original product page sentence.
| Projects | Public-Facing Positioning of This Page |
|---|---|
| Degrees of Freedom | Total active degrees of freedom: 21, broken down as dual arms 14, waist 3, legs 2, neck 2. |
| Load and Mass | Single-arm payload 5 kg. Total unit weight is approximately 125 kg, which is not the single-arm payload. |
| Form Factor and Scale | Overall dimensions 570 × 465 × 1680 mm. The chassis width and shoulder width are kept within 465 mm. |
| Operating Range | Vertical reach 2100 mm. Horizontal reach 1818 mm, excluding the end effector. |
| Motion | Motion speed 0.1–1.5 m/s. Turning radius 690 mm; the specification refers to in-place rotation. |
| Power | Battery 40 Ah (BMS). Charging time approximately 2 hours. The approximately 2 hours refers to charging, not runtime; the page does not state runtime in hours. |
| Perception & Compute | The vision system is listed as binocular depth / RGB optional. Wide-angle camera 130° FOV ×3, located on the chest / back / chassis. The LiDAR is a single-line laser with detection range greater than 40 m (90% reflectivity). The voice interaction module is a ring-shaped 6-microphone array, optional. Depth camera versions: data collection version Orbbec 335LG; standard version Intel RealSense D405; optional Intel RealSense D435. |
| End Effector | A multi-degree-of-freedom dexterous hand or gripper can be added to the end effector depending on the task. The page explicitly states compatibility with grippers and dexterous hands from Aoyi, Qiangnao, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard configuration list. |
| Boundary | The upper body and wheeled chassis are modular. How to connect to other chassis after separation must be confirmed per the project interface; do not state in the public table that it is already connected. |
| Configuration Panel | Both the voice module and depth camera versions have optional rows. Optional items are not included in unchecked deliveries. The end-effector brand must be specified by name in the configuration sheet; do not write "compatible means already included." |
| Excerptable | Attachment copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm maximum width; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end-effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; approximately 2 hours of charging. |
| Do not write | Do not write "approximately 2 hours of charging" as "2 hours of battery life." Do not attribute the folding model's 20 DoF or approximately 6 hours of battery life to this unit. Do not write the lifting model's 900 mm as this unit's lifting stroke. |

Relationship to Public Methods and Adjacent Pages
Acceptance attachments should replicate sentences that are already public on the product page and include units, and cite which page and which table they come from. Sentences that may be written are verifiable: model number, dimensions, mass, degrees of freedom and their locations, rated load, travel, speed, voltage capacity, communication, standard quantity. Sentences that may not be written are inferred statements: "equivalent to", "industry-leading", "six hours at full load", "includes gripper", "includes force feedback".
Even identical numbers get separate rows. ±0.05 mm appearing in both the arm's repeatability and the gripper's repeatability becomes two rows in the appendix. 5 kg appearing in single-arm rated load and gripper envelope load is also two rows. 48 V 20 Ah appearing in both the folding model and the lift model—whether hours follow it depends on each respective page.
Recommended attachment structure: 1. Excerpt from the standard quantity table; 2. Recommended items — if unchecked, they will not be delivered; 3. Optional items — state which column is selected or not selected for this order; 4. Explicitly excluded items, e.g., for the lift model do not list battery life in hours, do not list whole-machine degrees of freedom, and do not treat 8 kg as rated load.
This article lists the original sentences that this product may include in an appendix, along with a recommended exclusion statement.
Before handing off to a colleague
The binding order of the attachments is fixed: standard-row excerpts, recommended and optional checkmarks, not-included list, and synchronization and test booklets if any are bound separately. Test results do not appear in the specification excerpts. If test results are written into the same volume, they will be treated as specifications. The signature page repeats the product page path. If legal or procurement requires rewriting an original sentence, the rewritten draft must be traceable word by word back to the original sentence; words that cannot be traced are deleted. The words "approximately", "not included", "not specified", and "optional" are considered undeletable. Every page footer of the attachment contains the product page path and "an excerpt is not a rewrite". If a page is a checkmark page, the footer adds "unchecked equals not delivered". If a page is a not-included list, the footer adds "this page is an exclusion". If a test booklet exists, its cover uses a different color and states "tests are not specifications". When binding, the test booklet is not inserted in the middle of the specification excerpts. If inserted in the middle, it is returned for rebinding.
First, specification excerpts do not include test results.
Second, unchecked equals not delivered, written in the footer.
Third, the exclusions list gets its own page.
Fourth, the test booklet cover states that tests are not specifications.
Fifth, every rewrite must be traceable word by word.
Sixth, do not delete "approximately," "not included," "not provided," or "optional." Every line in a specification excerpt must be findable as continuous original text on the product page using the search function. If the continuous original text cannot be found, the line has been rewritten and must be returned. Keep the test log and the excerpt in separate volumes to avoid inserting the wrong one during binding. Write the product page path again in the footer; after binding, spot-check that the paths on the first and last pages are consistent.
