When specifications conflict, present the original text side by side rather than choosing the more flattering one. The sentences that need to be listed separately on the wheeled humanoid teleoperation platform page include: single-arm payload 5 kg. Total machine weight is approximately 125 kg, not single-arm payload. The upper body and wheeled chassis are a modular structure. How to connect to other chassis after separation is confirmed per the project interface, and should not be written on the public page as already connected. Battery 40 Ah (BMS). Charging time is approximately 2 hours. Approximately 2 hours refers to charging, not endurance; the page does not state endurance in hours. These look like they are describing "capabilities", but they are actually different rows. Once merged into a single sentence, each party will cite a different number at acceptance time.
Specification basis
Units follow the numbers. Millimeters, kilograms, newtons, seconds, revolutions per minute, volts, and ampere-hours must not be dropped when restating. Vertical arm reach: 2100 mm. Horizontal arm reach: 1818 mm, excluding the end effector. If the original source text omits units at certain points, the note "units not specified in the original" must be retained for external use, rather than deleting the note to make the numbers look cleaner.
Standard rows, recommended rows, and optional rows are also part of the specification, not a matter of copy tone. Both the voice module and the depth camera version have optional rows. Optional items are not written into the delivery if unchecked. The end-effector brand must be named in the configuration sheet; do not write "compatible means already included". When the cover slogan, parameter table, and quantity list are inconsistent, the product page for the wheeled humanoid teleoperation platform has chosen to list them in parallel rather than collapsing them into one line. Articles should be written following this discipline.
A paraphrase written for colleagues can be short, but each short phrase must be traceable back to a row in the table. Adjectives that cannot be traced back — for example "high load", "long battery life", "fully equipped cameras" — do not enter the specification summary. The authoritative table is at /product-body-humanoid.html.

How to Use This Page in This Version
Read the specifications of the wheeled humanoid teleoperation body row by row, not adjective by adjective. It is recommended to copy the product page table onto a check sheet, keeping the subject on each row. The following rows are the most likely to be merged, so mark them in different colors on the check sheet. Load and mass: single-arm load 5 kg. Overall machine weight approximately 125 kg — this is not the single-arm load. Geometry: overall dimensions 570 × 465 × 1680 mm. Chassis width and shoulder width are within 465 mm. Vertical arm reach 2100 mm. Horizontal arm reach 1818 mm, excluding the end effector. Motion: motion speed 0.1–1.5 m/s. Turning radius 690 mm, specified as in-place rotation. Power: battery 40 Ah (BMS). Charging time approximately 2 hours. Approximately 2 hours is charging, not endurance; the page does not state endurance in hours. Perception and computing: vision system is binocular depth / RGB, optional. Wide-angle cameras 130° FOV × 3, located at chest / back / chassis. LiDAR is single-line laser, detection range greater than 40 m (at 90% reflectivity). Voice interaction module is a ring-shaped 6-microphone array, optional. Depth camera versions: data-collection edition Aobi 335LG; standard edition Intel RealSense D405; optional Intel RealSense D435. End effector and missing items: a multi-degree-of-freedom dexterous hand or gripper can be added to the end according to the task. The page states compatibility with grippers and dexterous hands from Aoyi, BrainCo, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard-included list. The upper body and wheeled chassis are a modular structure. How to connect to other chassis after disassembly is confirmed per the project interface and must not be written in the public table as already connected.
There is only one rule for color: different subjects must not be painted the same color. Rated load and self-weight are not the same color. Envelope load and friction load are not the same color. Charging time and runtime are not the same color. Standard list and cover slogan are not the same color. Parameter-table model and standard-configuration model are not the same color. Force feedback and zero-force gravity compensation are not the same color.
The second column of the check sheet asks "can these be written in the same sentence?" The answer is often no. For example, you cannot write "rated 8 kg, endurance 6 hours," because 8 kg is the self-weight of the lift version, 6 hours appears only on the folding version, and the two machines cannot be combined into one sentence. The mergeable relationships of the wheeled humanoid teleoperation body are governed by its own table, not by the customary phrasing on another card.
On the checklist, fill in the third column with the source: the product page path /product-body-humanoid.html, and whether that row is standard, recommended, or optional. Both the voice module and the depth camera version have optional rows. Optional items are not written into the delivery scope unless checked. The end-effector brand must be named explicitly in the configuration sheet; do not write "compatible means included". Numbers without a source are erased from the checklist. Erasing is closer to being acceptable than keeping an approximation.
Finally, hand the check sheet to the person writing the contract, not to the person writing the poster first. The poster can be short, but every short phrase must be traceable to a full row on the check sheet. If it cannot be found, it must not appear in external text. Excerptable: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical arm reach 2100 mm; horizontal arm reach 1818 mm (excluding end); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; charging approximately 2 hours. This is the type of sentence that can be kept, not raw material for arbitrary conversion.
Line-by-Line Verification
Degrees of freedom. The full-body active degrees of freedom total 21, split as 14 for the dual arms, 3 for the waist, 2 for the legs, and 2 for the neck. This line only states the number of joints and body parts that have been publicly disclosed. It does not evaluate intelligence, and it does not automatically include the waist, legs, neck, or the whole-machine total that are not named on the page. When writing the action vector, channels are created only for the body parts listed in this line; body parts not listed remain blank. Do not write blanks as 0, because 0 would be treated by the training script as a real angle. Do not fill in the degrees-of-freedom integer from another device after this line to make the numbers add up. If the master-slave joint order is not given on the page, mark it as pending written configuration confirmation; do not number it yourself. In the specification summary, degrees of freedom are bound to body parts, with no standalone integer. The action vector creates channels only for the body parts named in this line; unnamed body parts are left blank, not filled with 0.
Load and quality. Single-arm payload 5 kg. Total unit weight is approximately 125 kg, not the single-arm payload. Every number in this line must be read together with its subject: rated, self-weight, total unit mass, envelope, friction, or gripping force. If the subject differs, the numbers cannot be merged into one figure, nor can any conversion not given on the page be performed. If field objects are heavier, the specification cannot be changed retroactively; a larger specification also does not prove that every grasping method reaches that limit. The tool mass is undetermined—do not write the arm's rated payload as the graspable object mass. The acceptance table retains the original units. In the specification summary, every mass figure retains the subject it has in the table. During acceptance, read the subject first and then the number; if the subject is inconsistent, split it into two rows.
Form factor and scale. Overall dimensions 570 × 465 × 1680 mm. Chassis width and shoulder width are kept within 465 mm. This line describes form factor or structural scale, used to check doors, elevators, tabletops, or transport — it is not an operating height, nor is it a reach. Do not add it to the vertical range. If the diagram shows protrusions, antennas, or human standing positions not present in this line, note separately that they are not part of the specifications. If weight appears in an adjacent line, do not write it into the dimension sentence. When relaying form factor numbers, do not round them to phrases like "about 1.7 meters" that lose the millimeter precision. Doors, elevators, and transport only check the form factor — do not treat this line as an operating height.
Operating range. Vertical arm reach: 2100 mm. Horizontal arm reach: 1818 mm, excluding the end effector. This row describes the range the hand or lift can reach; the definition must follow the original wording: vertical working range, arm reach, motion radius, or stroke — these cannot be added together or renamed. If "excluding the end effector" is stated, it must remain in the figure caption. If the original text does not specify units, retain the note "units not specified" — do not delete it for tidiness. When restating range figures, do not merge them with the overall height into a single "height." The figure caption retains the range definition from the original wording, as well as the terms "excluding end" or "units not specified."
Motion. Motion speed 0.1–1.5 m/s. Rotation radius 690 mm, the specification is in-place rotation. This line describes how the ground or main arm moves. Four-wheel four-drive, differential drive, in-place rotation radius, and rotational speed are terms for different mechanisms and cannot be substituted for one another. Published speed is a capability, not a recommended teaching speed; teaching may be slower, but slower speeds are recorded under experimental conditions and are not written back into the specification. Do not borrow content from other pages for pages that do not list slope climbing or positioning. Keep mechanism terms in their original wording and do not translate them into smoother synonyms. Teaching speed may be lower, but lower speeds are recorded under operating conditions and do not change the published capability in this line.
Power. Battery: 40 Ah (BMS). Charging time: approximately 2 hours. Approximately 2 hours is charging, not endurance; the page does not state endurance in hours. This row retains only the electrical terms that appear on the page: voltage, capacity, endurance, charging, current, or power. If there are no "hours," write that endurance is not provided — do not fill in hours from an adjacent page. Do not rename charging time as endurance. Rated and maximum values must be listed separately. Approximate values retain "approximately." Ampere-hours from multiple devices must not be summed and presented as one device's battery. When restating the electrical row, do not add hours or ampere-hours not present in the table. Hours, charging, or current that do not appear remain "not provided" and must not be copied in from an adjacent page.
Perception and computing. Vision system: binocular depth / RGB, optional. Wide-angle cameras: 130° FOV × 3, located at chest / back / chassis. LiDAR: single-line laser, detection range greater than 40 m (at 90% reflectivity). Voice interaction module: ring-shaped 6-microphone array, optional. Depth camera versions: data-collection edition Aobi 335LG; standard edition Intel RealSense D405; optional Intel RealSense D435. This row lists the items explicitly stated for sensors, computing, or communications, and retains the terms standard, included, optional, and optional-order. An optional item that is not selected does not count. If the cover conflicts with the list, cite the list while not pretending the cover statement does not exist. Headsets and gloves do not belong in this row. Processors, storage capacity, or camera channel counts that are not stated must not be drawn into the system diagram. When restating sensors, retain the distinctions between standard, optional, and cover. Optional sensors that have not been purchased do not enter this data dictionary.
End effector. The end effector can be fitted with a multi-degree-of-freedom dexterous hand or gripper depending on the task. The page specifies compatibility with grippers and dexterous hands from Aoyi, Qiangnao, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard-included list. This line states where contact or grasping occurs. Quick-change, compatible, and recommended are not models already in the box. The ring fixture on the main arm is not an end-effector gripper. Force, stroke, and payload remain as written in their respective rows and are not merged into a single system metric because they are mounted on a particular platform. Flange and protocol mappings that are not provided should be written as "to be confirmed," not "plug and play." When paraphrasing the end-effector row, do not write capabilities as a checklist. "Supports" or "compatible" without a model number cannot be treated as already delivered.
Boundary. The upper body and wheeled chassis are a modular structure. How to connect to other chassis after separation is confirmed per project interface, and should not be written in the public table as already connected. This line is a deliberately separated boundary on the page: another model, another column, another product page, or an interface that still requires project confirmation after modularization. The boundary is not a defect description; it is to prevent verbally buying two pages as one. When writing a proposal, copy the boundary into "Not Included in This Order." If equipment not included is later added, open a new configuration order; do not go back and change the body name in old samples. Two conflicting lines are kept side by side; do not pick the one that looks more complete. Equipment within the boundary requires a separate order; do not rename old samples to say it is already included.
Configuration column. Both the voice module and the depth camera version have optional rows. Optional items are not written into an unselected delivery. The end-effector brand must be named on the configuration sheet — do not write "compatible means included." This row distinguishes standard, recommended, and optional. Recommended and optional items are not delivered unless selected. If the standard row conflicts with the parameter table row, keep both rows and use "locked for this order" to indicate which one is actually delivered, rather than crossing out one row in the order without signing off. Price and lead time are not written into this row's restatement. Standard, recommended, and optional are split into three sentences in the summary and are not merged into "configured." Unselected recommended and optional items are written on the order as not delivered.
Excerptable. Attachable copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; approximately 2 hours to charge. This is the type of line that can be pasted into an attachment: it has a subject, includes units, and can be traced back to the original sentence on the product page. When pasting, keep words like approximately, excluding, not specified, optional, and recommended. Do not convert and leave only the result. If the same number has different meanings on two pages, write it as two separate lines in the attachment. Do not mix test protocols into specification excerpts. Only short sentences that can be traced back to a table belong in an external specification summary. When pasting into an attachment, include words like approximately, excluding, and optional along with the numbers.
Do not write. Do not write charging approximately 2 hours as endurance 2 hours. Do not write the folding version's 20 DoF or approximately 6 hours onto this machine. Do not write the lift version's 900 mm as this machine's lift stroke. This row consists of negative statements for review purposes. It does not describe what the equipment can do; it only prevents hours, degrees of freedom, load subjects, or cover slogans from an adjacent page from being written in. If a negative statement is triggered, revert to the original sentence on the product page — do not interpret it as "close enough." Success rates from external papers and total hours not published on this site must likewise not be written in. Before publishing the summary, run a full-text search using the negative statements. If the manuscript hits a negative statement, revert to the original sentence on the product page.
| Projects | Public-Facing Positioning of This Page |
|---|---|
| Degrees of Freedom | Total active degrees of freedom: 21, broken down as dual arms 14, waist 3, legs 2, neck 2. |
| Load and Mass | Single-arm payload 5 kg. Total unit weight is approximately 125 kg, which is not the single-arm payload. |
| Form Factor and Scale | Overall dimensions 570 × 465 × 1680 mm. The chassis width and shoulder width are kept within 465 mm. |
| Operating Range | Vertical reach 2100 mm. Horizontal reach 1818 mm, excluding the end effector. |
| Motion | Motion speed 0.1–1.5 m/s. Turning radius 690 mm; the specification refers to in-place rotation. |
| Power | Battery 40 Ah (BMS). Charging time approximately 2 hours. The approximately 2 hours refers to charging, not runtime; the page does not state runtime in hours. |
| Perception & Compute | The vision system is listed as binocular depth / RGB optional. Wide-angle camera 130° FOV ×3, located on the chest / back / chassis. The LiDAR is a single-line laser with detection range greater than 40 m (90% reflectivity). The voice interaction module is a ring-shaped 6-microphone array, optional. Depth camera versions: data collection version Orbbec 335LG; standard version Intel RealSense D405; optional Intel RealSense D435. |
| End Effector | A multi-degree-of-freedom dexterous hand or gripper can be added to the end effector depending on the task. The page explicitly states compatibility with grippers and dexterous hands from Aoyi, Qiangnao, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard configuration list. |
| Boundary | The upper body and wheeled chassis are modular. How to connect to other chassis after separation must be confirmed per the project interface; do not state in the public table that it is already connected. |
| Configuration Panel | Both the voice module and depth camera versions have optional rows. Optional items are not included in unchecked deliveries. The end-effector brand must be specified by name in the configuration sheet; do not write "compatible means already included." |
| Excerptable | Attachment copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm maximum width; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end-effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; approximately 2 hours of charging. |
| Do not write | Do not write "approximately 2 hours of charging" as "2 hours of battery life." Do not attribute the folding model's 20 DoF or approximately 6 hours of battery life to this unit. Do not write the lifting model's 900 mm as this unit's lifting stroke. |

Relationship to Public Methods and Adjacent Pages
The specification table is the acceptance criterion; the cover slogan is not. If a slogan and a parameter table conflict on the same page, the parameter table and configuration list take precedence, and the conflict itself must be stated in the article — not quietly resolved by picking a better-sounding number. Copying numbers across pages is even more dangerous: the battery life written for the folding model cannot be written onto the lift model just because the voltages are similar; the repeatability of positioning from the lift model's arm table cannot be written as the whole-body accuracy of the wheeled humanoid.
When reading a table, hold to three rules. First, units follow the numbers. Millimeters, kilograms, newtons, seconds, and degrees must not disappear from the sentence. When the source sentence has no unit, note "the source text did not state a unit; recorded here as millimeters based on context" rather than pretending the original wrote one. Second, adjacent rows cannot be merged. Rated load, self-weight, gripping force, and travel are four different things. Third, standard quantity, recommended configuration, and optional items go in three columns. Recommended is not the same as factory standard.
Data aggregation efforts like Open X-Embodiment illustrate the same point from the opposite direction: cross-embodiment training requires the action space and sensor configuration of each robot to be explicitly recorded. Merging the heights or batteries of three embodiments into a single "company parameter" means the training metadata is wrong from day one.
This article separates the numbers on the product page that are easily merged into a single sentence, and provides wording that can be placed into the configuration sheet. Separating them is not nitpicking wording; it is to avoid each side holding a different number at acceptance.
Before handing off to a colleague
After completing the specification checklist, have another person review only the checklist (not the product page) and trace every line back to the table. Delete any line that cannot be traced back. If two lines have the same color but different subjects, split them. If a cover sentence is parallel to the checklist, keep both sentences, but only cite the checklist in the external summary. Before publishing the summary, search for "left/right," "approximately," "fully equipped," and "standard includes." If these words are not followed by an original sentence, delete them down to the original sentence only. Write the verification date in the corner of the sheet, because the product page may be corrected later and the old summary must match the table at that time. The fourth column of the checklist sheet reads "Can this sentence stand on its own?" Sentences that cannot usually do so because they borrowed the subject of the next line. Split the two lines and read them again. If one of the split lines has no numbers, the numbers came from the other line and the merged sentence should be deleted. External briefs are limited to three lines, one subject per line. If more than three lines are needed, convert to a table; do not chain multiple numbers into one sentence with commas. Chaining numbers into one sentence is a common form of specification failure.
First, every number can be traced back to a table.
Second, if the subject differs, split the sentence.
Third, keep both the cover sheet and the checklist; the abstract only cites the checklist.
Fourth, "approximately", "not included", and "not specified" are not deleted.
Fifth, the verification date is written in the corner of the page.
Sixth, sentences that cannot be traced back are deleted, not polished.
