Wheeled Humanoid Teleoperation Body | Compare Three Bodies Side by Side: folding, lifting, and wheeled humanoid — each from its own table

Three platforms plus one kit plus one gripper make five cards, not a single averaged parameter. When comparing, place only that page's own sentences in each row. The reason the wheeled humanoid teleoperation platform was selected in this article can only come from its own statements: total active degrees of freedom 21, broken down as 14 for the dual arms, 3 for the waist, 2 for the legs, and …

2026-10-03
TOBI
Product Insights
Wheeled Humanoid Teleoperation Body | Compare Three Bodies Side by Side: folding, lifting, and wheeled humanoid — each from its own table
Product InsightsWheeled humanoid teleoperation robot2026-10-03

Three platforms plus one kit plus one gripper make five cards, not one averaged parameter set. When comparing, place only each page's own sentence in each row. The reasons the wheeled humanoid teleoperation platform is selected in this article can only come from its own sentences: total active degrees of freedom for the whole body is 21, broken down as 14 for the two arms, 3 for the waist, 2 for the legs, and 2 for the neck. Vertical reach is 2100 mm. Horizontal reach is 1818 mm, excluding the end effector. Motion speed is 0.1–1.5 m/s. Rotation radius is 690 mm, specified as in-place rotation. Battery is 40 Ah (BMS). Charging time is approximately 2 hours. Approximately 2 hours is charging, not endurance; the page does not give endurance in hours.

Three-way comparison

Quantities that cannot be used for ranking include: degree-of-freedom integers, whole-machine mass, battery amp-hours, and whether force feedback is present. Their definitions differ. Force feedback belongs to the kit's column, not to the three base units' default configurations. Endurance hours are only stated for the folding model.

The wheeled humanoid teleoperation platform is usually selected because the item cited above happens to be the task's constraint: height, door width, differential drive or four-wheel steering, in-place rotation, the main arm column, or the gripper's force and stroke. Not because a number in some row is larger.

The other two platforms in the comparison table are governed by their own product pages. This article does not write their numbers into the order for the wheeled humanoid teleoperation platform. The product center keeps the five cards separate precisely for this procedure.

Wheeled humanoid teleoperation robot
Figure 1 | Wheeled humanoid teleoperation platform. The caption only states that this is a device photo from the product page; the appearance is not interpreted as parameters not present in the table.

How to Use This Page in This Version

Each cell in the selection comparison table should contain only the original sentence from that page, with no adjectives. The wheeled humanoid teleoperation robotic platform column should contain at least: total active degrees of freedom 21, broken down as 14 for the two arms, 3 for the waist, 2 for the legs, and 2 for the neck. Overall dimensions 570 × 465 × 1680 mm. Chassis width and shoulder width are kept within 465 mm. Vertical arm reach 2100 mm. Horizontal arm reach 1818 mm, excluding the end effector. Movement speed 0.1–1.5 m/s. Turning radius 690 mm, measured as in-place rotation. Battery 40 Ah (BMS). Charging time approximately 2 hours. Approximately 2 hours is charging, not runtime; the page does not state runtime in hours. Single-arm payload 5 kg. Overall weight approximately 125 kg, not single-arm payload. For other columns, copy from the corresponding product page; do not fill them in from memory in this article. Memory is most likely to fill in approximately 6 hours, 900 mm, 690 mm, and 21 degrees of freedom in the wrong columns.

Do not rank. Do not rank degrees of freedom, mass, amp-hours, or speed as "higher is better." If the task involves a narrow doorway, a width limit of 465 mm may be more relevant than larger dimensions; if the task involves overhead work, vertical range or vertical reach is what matters; if the task involves master-slave force feedback, leave the embodiment column and look at the first two columns of the kit.

Kits and grippers do not go into the three-column rig table. Each occupies its own row. Writing force feedback into the folding-model cell, or writing 130 N into the wheeled-humanoid cell, is a column violation.

The conclusion of the comparison is written as "because a particular cell matches the task," not as "stronger overall." The matching cell must be clickable at /product-body-humanoid.html. If it cannot be clicked, the selection is not complete. Do not write charging approximately 2 hours as endurance 2 hours. Do not write the folding model's 20 DoF or approximately 6 hours onto this machine. Do not write the lifting model's 900 mm as this machine's lifting stroke.

Line-by-Line Verification

Degrees of freedom. Total active degrees of freedom is 21, broken down as 14 for both arms, 3 for the waist, 2 for the legs, and 2 for the neck. This row only states the number of joints and body parts that have been made public. It does not evaluate intelligence, and it does not automatically include the waist, legs, neck, or the whole-machine total that are not named on the page. When writing the action vector, only create channels for the body parts listed in this row; leave the parts not listed blank. Do not write blanks as 0, because 0 will be treated by the training script as a real angle. Also, do not fill in the degrees-of-freedom integer from another device after this row to make the numbers add up. If the master-slave joint order is not given on the page, mark it as pending written configuration confirmation; do not number it yourself. This cell in the comparison table should only contain the original degrees-of-freedom sentence from this page. The action vector only creates channels for the body parts named in this row; leave unnamed parts blank and do not fill in 0.

Load and mass. Single-arm payload 5 kg. Total machine weight is approximately 125 kg, not the single-arm payload. The numbers in this line must be read aloud with their subject: rated, self-weight, total machine mass, envelope, friction, or gripping force. If the subjects differ, they cannot be merged into a single number, nor can conversions not given on the page be performed. If field objects are heavier, this does not retroactively change the specification; a larger specification does not prove that every grasping method reaches that limit. Tool mass is undetermined, so do not write the arm's rated value as the graspable object mass. The acceptance checklist retains original units. The comparison table does not put the masses of three machines into the same "load" cell. During acceptance, read the subject first and then the number; if the subjects are inconsistent, split them into two lines.

Dimensions and scale. Overall dimensions are 570 × 465 × 1680 mm. The chassis width and shoulder width are kept within 465 mm. This row is an external or structural scale, used to check doors, elevators, tabletops, or transport; it is not an operating height, nor is it a reach. Do not add it to the vertical range. If the diagram shows protrusions, antennas, or a person's standing position not listed in this row, note separately that they are not part of the specification. If weight appears in an adjacent row, do not write it into the dimension sentence. Each of the three platforms' external dimensions occupies its own cell. Doors, elevators, and transport are checked only against the external dimensions; do not treat this row as an operating height.

Operating range. Vertical reach is 2100 mm. Horizontal reach is 1818 mm, excluding the end effector. This row describes the range that the hand or lift can reach; the definition must follow the original sentence: vertical working range, reach, motion radius, or stroke. These cannot be added together or renamed. If "excluding end effector" is written, it must remain in the figure caption. If the original text does not specify units, retain the note "units not specified"; do not delete it for tidiness. Vertical range, lifting stroke, and vertical reach are not merged into a company standard height. The figure caption retains the range definition from the original sentence, as well as the words "excluding end effector" or "units not specified."

Motion. Motion speed 0.1–1.5 m/s. Rotation radius 690 mm, specified as in-place rotation. This row describes how the ground platform or the main arm moves. Four-wheel four-wheel-drive, differential drive, in-place rotation radius, and rotational speed are terms for different mechanisms and cannot be substituted for one another. Published speed is a capability, not a recommended demonstration speed; demonstration may be slower, but a slower speed is recorded under experimental conditions and is not written back into the specification. Do not borrow slope-climbing or positioning figures from other pages onto a page that does not list them. Each of the three motion terms occupies its own field. Demonstration speed may be lower, but a lower speed is recorded under the operating conditions and does not change the published capability in this row.

Power. Battery 40 Ah (BMS). Charging time approximately 2 hours. Approximately 2 hours is charging, not endurance; the page does not give endurance in hours. This row retains only the electrical terms that appear on the page: voltage, capacity, endurance, charging, current, or power. If there are no "hours," write that endurance is not specified; do not fill in hours from an adjacent page. Do not rename charging time as endurance. Rated and maximum values are listed separately. Approximate values retain "approximately." Do not sum the ampere-hours of multiple devices and present the total as one device's battery. Hours appear only in cells where hours are written. Hours, charging, or current that do not appear remain not specified; do not copy them in from an adjacent page.

Perception and computing. The vision system offers stereo depth / RGB as options. Wide-angle cameras: 130° FOV × 3, positioned on the chest / back / chassis. The LiDAR is a single-line laser with a detection range greater than 40 m (90% reflectivity). The voice interaction module is a ring of 6 microphones, optional. Depth camera versions: Orbbec 335LG for the data-capture edition; Intel RealSense D405 for the standard edition; Intel RealSense D435 optional. This row inventories the items already specified under sensors, computing, or communications, and retains the terms standard, included, optional, and optional upgrade. An unselected optional item does not count. Where the cover conflicts with the checklist, cite the checklist — while not pretending the cover statement does not exist. Head-mounted devices and gloves do not belong in this row. Processors, storage capacity, or camera channel counts that are not written out must not be drawn into the system diagram. Camera configuration does not factor into the platform ranking. Optional sensors that have not been purchased do not enter this data dictionary.

End effector. A multi-DoF dexterous hand or gripper can be added to the end effector depending on the task. The page states compatibility with grippers and dexterous hands from Aoyi, BrainCo, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard-configuration list. This row describes where contact or grasping occurs. Quick-change, compatible, and recommended are not models included in the box. The ring gripper on the main arm is not an end-effector gripper. Force, stroke, and payload remain as stated in their respective rows and are not merged into a single system metric because they are mounted on a particular body. Flange and protocol mappings that are not specified should be marked as pending confirmation, not plug-and-play. End-effector capabilities are not included in the body comparison's overall score. "Supports" or "compatible" without a model name cannot be treated as delivered.

Boundary. The upper body and wheeled chassis are a modular structure. How they connect to other chassis after separation must be confirmed per project interface and must not be written in the public table as already connected. This row is a boundary deliberately separated on the page: another model, another column, another product page, or an interface that still requires project confirmation after modularization. The boundary is not a defect note; it prevents verbally merging two pages into one. When writing a proposal, copy the boundary into "not included in this scope." If equipment not included is added later, open a new configuration sheet; do not retroactively change the body name in the old sample. The kit column and gripper row are not mixed into the body's three columns. Equipment within the boundary must be ordered separately; do not rename the old sample to imply it is already included.

Configuration column. Both the voice module and depth camera versions have optional rows. Optional items are not included in the deliverables unless checked. The end-effector brand must be named explicitly in the configuration sheet; do not write "compatible means already included." This row distinguishes standard, recommended, and optional. Recommended and optional items are not delivered unless checked. When the standard row and the parameter table row are inconsistent, keep both rows and use "locked for this order" to indicate which one is actually delivered, rather than striking out one row in the order without a signature. Price and lead time are not written into this row's paraphrase. Recommended items are not written as standard on all three units. Unchecked recommended and optional items are written as not delivered on the order.

Excerptable. The following can be copied into an appendix: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm width limit; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end effector); in-place turning radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; charging approximately 2 hours. This row is the type of content that can be pasted into an appendix: it has a subject, includes units, and can be traced back to the original sentence on the product page. When pasting, preserve words like "approximately," "excluding," "not specified," "optional," and "recommended." Do not convert units and keep only the result. If the same number has different meanings on two pages, write it as two separate rows in the appendix. Do not mix test protocols into specification excerpts. Selection conclusions should cite the matching cell, not claim overall superiority. When pasting into an appendix, include words like "approximately," "excluding," and "optional" along with the values.

Do not write. Do not write "charging approximately 2 hours" as "battery life 2 hours." Do not write the folding model's 20 DoF or approximately 6 hours onto this unit. Do not write the lift model's 900 mm as this unit's lift stroke. This row is a negative statement for review purposes. It does not describe what the equipment can do; it only prevents hours, degrees of freedom, payload subjects, or cover slogans from neighboring pages from being written in. If a negative statement is triggered, revert to the original sentence on the product page; do not interpret it as "close enough." Do not write in success rates from external papers or total hours not published on this site. Remove concatenated numbers from the comparison table. If a draft search triggers a negative statement, revert to the original sentence on the product page.

ProjectsPublic-Facing Positioning of This Page
Degrees of FreedomTotal active degrees of freedom: 21, broken down as dual arms 14, waist 3, legs 2, neck 2.
Load and MassSingle-arm payload 5 kg. Total unit weight is approximately 125 kg, which is not the single-arm payload.
Form Factor and ScaleOverall dimensions 570 × 465 × 1680 mm. The chassis width and shoulder width are kept within 465 mm.
Operating RangeVertical reach 2100 mm. Horizontal reach 1818 mm, excluding the end effector.
MotionMotion speed 0.1–1.5 m/s. Turning radius 690 mm; the specification refers to in-place rotation.
PowerBattery 40 Ah (BMS). Charging time approximately 2 hours. The approximately 2 hours refers to charging, not runtime; the page does not state runtime in hours.
Perception & ComputeThe vision system is listed as binocular depth / RGB optional. Wide-angle camera 130° FOV ×3, located on the chest / back / chassis. The LiDAR is a single-line laser with detection range greater than 40 m (90% reflectivity). The voice interaction module is a ring-shaped 6-microphone array, optional. Depth camera versions: data collection version Orbbec 335LG; standard version Intel RealSense D405; optional Intel RealSense D435.
End EffectorA multi-degree-of-freedom dexterous hand or gripper can be added to the end effector depending on the task. The page explicitly states compatibility with grippers and dexterous hands from Aoyi, Qiangnao, Zhixing, and others, as well as the RX75, RM75, and RM65 robotic arm platforms. Compatibility is not a standard configuration list.
BoundaryThe upper body and wheeled chassis are modular. How to connect to other chassis after separation must be confirmed per the project interface; do not state in the public table that it is already connected.
Configuration PanelBoth the voice module and depth camera versions have optional rows. Optional items are not included in unchecked deliveries. The end-effector brand must be specified by name in the configuration sheet; do not write "compatible means already included."
ExcerptableAttachment copy: 21 (14+3+2+2); 570×465×1680 mm; approximately 125 kg; 465 mm maximum width; vertical reach 2100 mm; horizontal reach 1818 mm (excluding end-effector); in-place rotation radius 690 mm; 0.1–1.5 m/s; single arm 5 kg; 40 Ah; approximately 2 hours of charging.
Do not writeDo not write "approximately 2 hours of charging" as "2 hours of battery life." Do not attribute the folding model's 20 DoF or approximately 6 hours of battery life to this unit. Do not write the lifting model's 900 mm as this unit's lifting stroke.
Another image from the wheeled humanoid teleoperation platform image library
Figure 2 | Another image from the product page gallery. The page does not label this image as front view or side view, so no view name is added here.

Relationship to Public Methods and Adjacent Pages

Do not merge the three platforms into a single product-line spec. The folding dual-arm, lift dual-arm, and wheeled humanoid platforms solve different ground and manipulation-height problems. The purpose of comparison is selection, not proving that one unit is "more advanced." Degrees of freedom count, total mass, and battery capacity cannot be ranked, because their definitions differ.

Folding type: 20 active degrees of freedom, four-wheel steering with drive, vertical 0–2.1 m, dimensions approximately 614×552×1700 mm, mass approximately 125 kg, 48 V 20 Ah, endurance approximately 6 hours, single-arm rated load 5 kg. Lift type: model RMC-AIDAL, folded dimensions 640×450×1780 mm, mass approximately 80 kg, vertical 0–2.4 m, lift stroke 900 mm, differential drive, single-arm rated load per the arm table is 5 kg, the self-weight 8 kg is the arm mass; battery 48 V 20 Ah but no endurance in hours; whole-machine degrees of freedom not published. Wheeled humanoid: 21 active degrees of freedom (arms 14, waist 3, legs 2, neck 2), dimensions 570×465×1680 mm, mass approximately 125 kg, turning radius 690 mm, 40 Ah, charging approximately 2 hours, single-arm rated load 5 kg.

Kits and grippers do not participate in this base-unit comparison. They are separate line items.

This article uses comparison to help choose that product, and specifies on which point it cannot be interchanged with the other two.

Before handing off to a colleague

After completing the comparison table, cover the other columns, read only the selected column, and ask yourself: is the task constraint one of the cells in this column? If you cannot name that cell, you have not finished selecting. Do not add or average numbers across several columns before selecting. If kits and grippers are written into the embodiment column, the entire table is void and must be rewritten. The conclusion sentence uses only "because a certain cell matches," never "composite score." Every cell in the table can point to the corresponding product page. The comparison table uses paper or a spreadsheet, not a paragraph. A paragraph will inevitably use "and" to link the numbers of two devices, and readers will remember them as one device. Each cell holds only one original sentence. If it does not fit, wrap to a new line; do not abbreviate it into a new number. After selecting, fold the unselected columns and clip only the selected column into the experiment plan. Unselected columns remain in the selection archive and do not appear on the wall at the capture site, to prevent on-site personnel from mixing them up.

First, use a table, not a paragraph.

Second, one original sentence per cell.

Third, do not average, do not add.

Fourth, kits and grippers do not go in the main unit column.

Fifth, the conclusion should only state that a particular cell matches.

Sixth, unselected columns are not posted at the capture site. After selection, copy the original sentence from that cell into the first page of the experiment plan and write the product page path. If the first page does not contain the original sentence, on-site personnel will fall back on memory — and memory is the source of column violations.
